Home > Hubbell Lighting > Beacon CLO-80L-50-3K7-5QW-UNV-SQ-WHT Square Ceiling Garage Light, 6000 Lumens, 3000K, 70 CRI, Type 5 Square Wide Optics, 120-277V, White Matte Textured
Beacon CLO-80L-50-3K7-5QW-UNV-SQ-WHT Square Ceiling Garage Light, 6000 Lumens, 3000K, 70 CRI, Type 5 Square Wide Optics, 120-277V, White Matte Textured
Beacon CLO-80L-50-3K7-5QW-UNV-SQ-WHT Square Ceiling Garage Light, 6000 Lumens, 3000K, 70 CRI, Type 5 Square Wide Optics, 120-277V, White Matte Textured
Email or call us at 310-822-6500 for pricing
For project,
request a quote
Ordering a large quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
CONSTRUCTION
CONSTRUCTION
- Die-cast housing with hidden vertical heat fins are optimal for heat dissipation while keeping a clean smooth outer surface
- Mounted with two key-slotted screws for easy installation and removal
- Galvanized steel housing mounts to 1/2" EMT conduit, contains pre-wired junction box with knockouts for easy access
- Driver mounted with accessiblity from beneath for easy services
- Optical one piece cartridge system consisting of an LED engine, LED lamps, optics and gasket
- One-piece silicone gasket ensures a weatherproof seal
- Micro Strike Optics (80 LED counts) maximize uniformity in applications and come standard with mid-power LEDs which evenly illuminate the entire luminous surface area to provide a low glare appearance
- Strike Optics (18 LED counts) provide best in class distributions and maximum spacing in new applications with high powered LEDs. Strike optics are held in place with a polycarbonate bezel to mimic the appearance of the Micro Strike Optics so both solutions can be combined on the same application
- Field rotatable optics
- 100–277V, 50–60 Hz (UNV)
- Power factor is ≥ .90 at full load
- Comes standard with 0–10V dimming capability, with flicker-free dimming to 10%. Must contact factory to request wiring leads for purpose of external dimming controls
- Component-to-component wiring within the luminaire may carry no more than 80% of rated load and is certified by UL for use at 600VAC at 90°C or higher
- Surge protection - 20kA
- The luminaire us UL Listed for use in wet locations in outdoor canopies
- 5 year warranty
Download PDF SpecificationShare your knowledge of this product. Be the first to write a review »
