Home > Hubbell Lighting > Hubbell Outdoor Lighting LNC2-12L-3K-070-2-U-BLT Small Lite LED Wallpack, 12 LEDs, 700mA, Type II Distribution, 120-277V, Black Matte Textured
Hubbell Outdoor Lighting LNC2-12L-3K-070-2-U-BLT Small Lite LED Wallpack, 12 LEDs, 700mA, Type II Distribution, 120-277V, Black Matte Textured
Hubbell Outdoor Lighting LNC2-12L-3K-070-2-U-BLT Small Lite LED Wallpack, 12 LEDs, 700mA, Type II Distribution, 120-277V, Black Matte Textured
Regular price
Price:
$418.52
Regular price
Price:
Sale price
$418.52
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
CONSTRUCTION
CONSTRUCTION
- Rugged die-cast aluminum housing protects components and provides an architectural appearance
- Casting thermally conducts LED heat to optimize performance and long life
- Powder paint finish provides durability in outdoor environments
- Zero uplight distributions using individual acrylic
- LED optics provide IES type II, III and IV distributions. Optional (CS) acrylic diffuser available for reduced glare
- Prismatic refractor lens provides - 10% uplight for increased vertical footcandles and forward light projection ideal for security lighting
- L96 at 60,000hrs (Projected per IESNA TM-21-11), see table on page 3 for all values
- Quick-mount adapter provides easy installation to wall or to recessed junction boxes (4" square junction box)
- Designed for direct j-box mount.
- Optional 1/2” conduit hubs available (standard for sensor, SiteSync and battery versions)
ELECTRICAL
CONTROLS- 120V-277V universal voltage 50/60Hz 0-10V dimming drivers
- 347V and 480V dimmable driver option in 12L-070 configuration
- Minimum operating temperature is -40˚C/-40˚F (excludes 12L-035 and P15 configurations)
- Drivers have greater than .90 power factor and less than 20% Total Harmonic Distortion
- Driver RoHS and IP66
- 10kA surge protector
- 3000K CCT nominal, 4000K CCT nominal, 5000K CCT nominal (70 CRI)
- 9, 12 and 18 LED configurations available see pages 2 and 3 for electrical and photometric details
- Universal button photocontrol
- Occupancy sensor options available for complete on/off and dimming control
- SiteSync pre-commissioned wireless controls (with or without sensor)
- Integral Battery Backup provides emergency lighting for the required 90 minute path of egress
- Dual Driver and Dual Power Feed option for 18L-070 versions
CERTIFICATIONS
WARRANTY- DLC DesignLights Consortium Qualified, with some Premium Qualified configurations. Please refer to the DLC website for specific product qualifications at www.designlights.org
- Listed to UL1598 and CSAC22.2#250.0-24 for wet locations
- Made-to-order versions are IP-65 rated
- This product qualifies as a "designated country construction material” per FAR 52.225-11 Buy American-Construction Materials under Trade Agreements effective 04/23/2020. See Buy American Solutions
- 5 year limited warranty
