Columbia Lighting LSTE22-35-MLG-MPO-EDU 40W 2' x 2' Stratus LED Architectural Recessed Light, 3500K, 3325-3625 Lumens, Grid Lay-In Ceiling Type, Metal Perforated with Overlay Shielding, 0-10V Dimming, 120-277V

Columbia Lighting LSTE22-35-MLG-MPO-EDU 40W 2' x 2' Stratus LED Architectural Recessed Light, 3500K, 3325-3625 Lumens, Grid Lay-In Ceiling Type, Metal Perforated with Overlay Shielding, 0-10V Dimming, 120-277V

Price: $241.83
Price: $241.83

MODEL: CL-LSTE22-35-MLG-MPO-EDU
Add To Wishlist
Request a Quote
Ordering a large quantity? Request a quote
View full details

description

PRODUCT SPECIFICATIONS
CONSTRUCTION
  • Luminaire housing and end caps are die formed code gauge cold rolled steel
  • The sturdy reflector is stiffened with linear forms, profiled to a precision curve
  • Basket and all reflective surfaces are finished after fabrication with unique formula high reflectivity matte white paint for soft, uniform indirect illumination
  • Basket hinges down for easy access to center wireway
OPTICS
  • Perforated basket with high transmission overlay for improved optical efficiency plus lamp obscuration
  • Thermoplastic light traps snap into the housing at both ends of the basket to prevent light leaks
INSTALLATION
  • An access plate is furnished with each luminaire for fast wiring access without the necessity to open the fixture or wireway
  • Luminaire fits recessed exposed Grid ceilings (G); four integral NEC compliant T-bar clips are standard\
  • Can be placed in Slot Grid (SG) style ceiling with regress 3/8" above ceiling plane
  • A Flange Kit (FK) accessory is available for recessed hard ceiling applications
  • Surface Mount (SM) option allows placement below ceiling plane
  • Cable Mount (CM) option allows suspension below ceiling plane
ELECTRICAL
  • 60,000 hour LEDs at L80 for reduced maintenance
CERTIFICATIONS
  • IC label is standard for recessed products. IC label is void on VL if product is installed on site with through wiring
  • All luminaires are built to UL 1598 and 2108 standards, and bear appropriate
  • cCSAus labels
  • CSA certified to UL 924 standards with battery pack or DTS (Dimming Bypass Module) options
  • Damp Location label standard
  • Emergency-equipped fixtures are Dry Location unless specified
  • Adheres to LM79, LM80, and TM21 industry standards
  • The DTS, Dimming Bypass Module, is for emergency circuit control loads including sensors and wireless systems CSA certified to UL 924.
  • This product qualifies as both (i) a "domestic construction material" per FAR §52.225-9 Buy American-Construction Materials and a "(COTS) item" per FAR §2.101 and (ii) a "designated country construction material" per FAR 52.225-11 Buy American-Construction Materials under Trade Agreements effective 06/01/2020.
WARRANTY
  • 5 year warranty
