Columbia Lighting CBT22-A-LSCS-EDD 2'x2'' Back-Lit LED Troffer, Selectable 4400/3300/2750 Lumens, Selectable 3500/4000/5000K, Dim to Off

Columbia Lighting CBT22-A-LSCS-EDD 2'x2'' Back-Lit LED Troffer, Selectable 4400/3300/2750 Lumens, Selectable 3500/4000/5000K, Dim to Off

Price: $66.91
Price: $66.91

MODEL: CL-CBT22-A-LSCS-EDD
Add To Wishlist
Request a Quote
Ordering a large quantity? Request a quote
View full details

description

PRODUCT FAMILY SPECIFICATIONS
CONSTRUCTION
  • Aluminum lens frame has a matte white finish
  • Luminaire housing is die formed code-gauge steel
  • Low profile design is ideal for shallow plenum applications
OPTICS
  • Acrylic micro-optics over each LED provide edge to edge illumination without pixelation or bright spots
  • Frosted textured lens provides smooth surface brightness
INSTALLATION
  • Integral T-bar clips for secure mounting to 9/16" and 15/16" grid ceiling
  • For surface mount applications use surface mount kit accessories
  • For plaster or sheet rock installations, use flange kit accessories
  • For cable mount applications use surface mount kit accessory and cable kit accessory
ELECTRICAL
  • 60,000 hour LEDs at L90 for reduced maintenance
  • Operates at 120–277V. 1V minimum low end trim recommended when paired with a 0-10V dimmer
  • 0-10V 1% Dim to Off driver is standard. See additional info on page 6
  • Switchable luminaire default settings at highest lumen output and 3500K
PACKAGING
  • All CBT LSCS Generation A units are priced as single units and must be ordered as single units. Two packaging options are available
CERTIFICATIONS
  • All luminaires are built to UL 1598 standards and bear appropriate cULus labels
  • Damp location label standard
  • Adheres to LM79, LM80, and TM21 industry standards for photometrics and lifetime calculations
  • DLC® (DesignLights Consortium Qualified.) Please refer to the DLC website for specific product qualifications at www.designlights.org
  • UL Sanitation Certified to NSF 2 Food Equipment standard for non-food zones
  • Tested in accordance with ISO 14644-1; suitable for ISO Class 4-9 positive and negative pressure clean rooms
  • Emergency battery options are California Energy Commission (CEC) Title 20 Compliant
  • Suitable for ambient temperatures from -25°C to 25°C
WARRANTY
  • 5 year warranty
