Columbia Lighting CL-CBT24-A-LSCS-EDD-2PK 2'x4' Back-Lit Troffer, 5500/4400/3300 Switchable Lumens, 3500/4000/5000K Switchable CCT, 2-Pack
Columbia Lighting CL-CBT24-A-LSCS-EDD-2PK 2'x4' Back-Lit Troffer, 5500/4400/3300 Switchable Lumens, 3500/4000/5000K Switchable CCT, 2-Pack
Regular price
Price:
$214.34
Regular price
Price:
Sale price
$214.34
Unit price
per
Ordering a large quantity?Request a quote
description
PRODUCT SPECIFICATIONS
CONSTRUCTION
CONSTRUCTION
- Aluminum lens frame has a matte white finish
- Luminaire housing is die formed code-gauge steel
- Low profile design is ideal for shallow plenum applications
- Acrylic micro-optics over each LED provide edge to edge illumination without pixelation or bright spots
- Frosted textured lens provides smooth surface brightness
- Integral T-bar clips for secure mounting to 9/16" and 15/16" grid ceiling
- For surface mount applications use surface mount kit accessories
- For plaster or sheet rock installations, use flange kit accessories
- 60,000 hour LEDs at L90 for reduced maintenance
- Operates at 120–277V. 1V minimum low-end trim recommended when paired with a 0-10V dimmer
- 0--10V 1% Dim to Off driver is standard. See additional info on page 6
- Switchable luminaire default settings at highest lumen output and 3500K
- All CBT LSCS Generation A units are priced as single units and must be ordered as single units in even quantities, as this product is packed two fixtures per box. It should be noted in receiving documents that one box has two units and should be received as two units
CERTIFICATIONS
- All luminaires are built to UL 1598 standards and bear appropriate cULus labels
- Damp location label standard
- Adheres to LM79, LM80, and TM21 industry standards for photometrics and lifetime calculations
- DLC (DesignLights Consortium Qualified.)
WARRANTY
- 5 year warranty
Download PDF Specification Share your knowledge of this product. Be the first to write a review »
