PRODUCT SPECIFICATIONS
CONSTRUCTION
Housing, wireway, and ends are formed from code-gauge steel. Housing components act as heat sink for LED heat dissipation. Knockouts are provided for electrical access and mounting.
FINISH
White painted parts are treated with a five-stage phosphate bonding process and finished with high reflectance baked enamel. For a post-painted housing finish select PAF option.
ELECTRICAL
Long-life LEDs are rated for 50,000 hours at L80 lumen maintenance. Driver options include fixed output for on/off function, step dimming (high/low/ off) or continuous 0-10V dimming.
CERTIFICATION
All luminaires are built to UL 1598 and 2108 standards, and bear appropriate CSA c/US labels. Damp location labeling is standard. CSA certified to UL 924 standards with battery pack option. Adheres to LM70, LM80, and TM21 industry standards.
WARRANTY
Five year warranty (Terms and Conditions apply).
CONSTRUCTION
Housing, wireway, and ends are formed from code-gauge steel. Housing components act as heat sink for LED heat dissipation. Knockouts are provided for electrical access and mounting.
FINISH
White painted parts are treated with a five-stage phosphate bonding process and finished with high reflectance baked enamel. For a post-painted housing finish select PAF option.
ELECTRICAL
Long-life LEDs are rated for 50,000 hours at L80 lumen maintenance. Driver options include fixed output for on/off function, step dimming (high/low/ off) or continuous 0-10V dimming.
CERTIFICATION
All luminaires are built to UL 1598 and 2108 standards, and bear appropriate CSA c/US labels. Damp location labeling is standard. CSA certified to UL 924 standards with battery pack option. Adheres to LM70, LM80, and TM21 industry standards.
WARRANTY
Five year warranty (Terms and Conditions apply).
