Dual Lite LESWSRXWAW Wall Mount Architectural Edge-Lit LED Exit Sign, Single Face, Red Letters, No Arrows Exit, White Finish, AC Only, White Plaque Background

Application
The LES Series provides bright, even letter illumination in an energy-saving LED edge-lit exit sign configuration. AC only operation. Special Wording ("SW") option allows customizing the stencil field to convey important information.

Construction
Water-clear injection-molded acrylic EXIT plaque is available with clear, white or mirror backgrounds. High strength extruded aluminum trim available in six finishes. Exit face design in single or double face with red or green letters. Custom printed directional chevron arrows. Standard EXIT stencil with 6" letters and 3/4" stroke.

Installation
Mounts to standard electrical boxes up to 4" square via universal adaptor plate and mounting canopy assembly. All mounting hardware is fully concealed.

Illumination
Exit face illumination is provided by energy saving, long life red or green LEDs. Exceeds UL 924 requirements for brightness and uniformity.

Compliances
UL 924 Listed
N F PA 70
NFPA 101
CEC T20 Compliant

Warranty
5 years full

Ordering Information
