Focus Industries AL-03-4T10LED3BRT 12V 3W Omni LED Cast Aluminum 10" 4 Tier Pagoda Hat Area Light, Bronze Texture Finish
Focus Industries AL-03-4T10LED3BRT 12V 3W Omni LED Cast Aluminum 10" 4 Tier Pagoda Hat Area Light, Bronze Texture Finish
10% off on $500 order or more
Regular price
Price:
$131.49
Regular price
Price:
Sale price
$131.49
Unit price
per
Ordering a large quantity?Request a quote
Download PDF Spec & Brochure
description
CONSTRUCTION: Cast aluminum Pagoda Hat with matching extruded aluminum stanchion.
AL-03-4T LENS: 7" tall clear tempered glass
LAMP SUPPLIED: 3w 50,000 hours average rating OMNI-3 LED (-LED3)
SOCKET: Single contact bayonet, brass nickel plated lamp socket screw shell (Ba15s); double contact bayonet base (Ba15d) for 120v, both with 200°C silicone lead wires
WIRING: Black 3 foot 18/2 zip cord from base of fixture (12v only)
For 25 foot 16/2 fixture lead wire add -25F to catalog number.
120v Standard wiring
CONNECTION: FA-05 Quick Connector (not supplied) from fixture to main cable
(12/2, 10/2 or 8/2 only) 12v only
MOUNTING: FA-03 black 9" ABS stake, tapped 1/2" NPS
AL-03-4T LENS: 7" tall clear tempered glass
LAMP SUPPLIED: 3w 50,000 hours average rating OMNI-3 LED (-LED3)
SOCKET: Single contact bayonet, brass nickel plated lamp socket screw shell (Ba15s); double contact bayonet base (Ba15d) for 120v, both with 200°C silicone lead wires
WIRING: Black 3 foot 18/2 zip cord from base of fixture (12v only)
For 25 foot 16/2 fixture lead wire add -25F to catalog number.
120v Standard wiring
CONNECTION: FA-05 Quick Connector (not supplied) from fixture to main cable
(12/2, 10/2 or 8/2 only) 12v only
MOUNTING: FA-03 black 9" ABS stake, tapped 1/2" NPS
