Focus Industries RXT-12-600MVT 600 watt Multi Volatge Stainless Steel transformer, output voltage 12.5V, 13.5V and 14.5V with Mechanical Timer
Focus Industries RXT-12-600MVT 600 watt Multi Volatge Stainless Steel transformer, output voltage 12.5V, 13.5V and 14.5V with Mechanical Timer
10% off on $500 order or more
Regular price
Price:
$748.34
Regular price
Price:
Sale price
$748.34
Unit price
per
Ordering a large quantity?
Request a quote
Find your items based on model numbers and product specification. Photo might not represent the actual item or color.
description
MATERIAL/FEATURES
UL 1838 listed, the standard for low voltage landscape lighting systems
60, 120, 180, 300 and 600 watt output models available
Multi Voltage output standard(12.5, 13.5 & 14.5 Volts)
Super Terminal Lugs with capacity of 3 x #8, 5 x #10, 7 x #12 or 9 x #14 gauge wire
304 Stainless Steel enclosure with No. 4 brushed finish
Removable hinged door is lockable and weather sealed
Above grade, NEMA 3R rated, rain tight enclosure
LED indicators for instant recognition of 120v and 12v power
Timer Ready standard (for plug in timers)
Optional Mechanical Timer (-T), Digital Timer (-DT) and Astro Timer (-AT) face plates can be factory or field installed
Photocell Ready with quick connector (not on -AT models)
Supplied with two 1/2" conduit (trade size) holes & one 1-1/2" inlet with plugs in bottom panel plus 2 side panel 1/2" conduit (trade size) holes with plugs
Break away bottom panel swings down for easy access wiring
11 gauge cold rolled steel ‘L’ brackets for stable mounting
Mounting plate and hardware included
FINISH
Brushed Stainless Steel
ELECTRICAL
Long life, high efficiency 266 degree F (130 degree C) class 'B' rated transformer core
Copper Shielded isolation/insulation; No contact between 120v and 12v windings
1500v Isolation between all windings and ground
Grade M19 electric grade steel for superior electrical and magnetic properties
Single phase, open core and coil
E.L. laminated core has concentric winding and is protected by 180 degree C thermal switch.
Double vacuumed impregnated with black slate flour
Filled varnish for superior heat dissipation and noise reduction -- Class 180 degree C
120v primary, 12.5v secondary 50/60 Hertz/cycle (standard)
6 foot 18/3 SJT-WA weatherproof grounded power cord (120v)
ON/OFF control via rocker switch on 120v side
Extra heavy duty (80 amp) terminal lugs
Manually resettable circuit breakers on front panel for overload and short circuit protection
UL 1838 listed, the standard for low voltage landscape lighting systems
60, 120, 180, 300 and 600 watt output models available
Multi Voltage output standard(12.5, 13.5 & 14.5 Volts)
Super Terminal Lugs with capacity of 3 x #8, 5 x #10, 7 x #12 or 9 x #14 gauge wire
304 Stainless Steel enclosure with No. 4 brushed finish
Removable hinged door is lockable and weather sealed
Above grade, NEMA 3R rated, rain tight enclosure
LED indicators for instant recognition of 120v and 12v power
Timer Ready standard (for plug in timers)
Optional Mechanical Timer (-T), Digital Timer (-DT) and Astro Timer (-AT) face plates can be factory or field installed
Photocell Ready with quick connector (not on -AT models)
Supplied with two 1/2" conduit (trade size) holes & one 1-1/2" inlet with plugs in bottom panel plus 2 side panel 1/2" conduit (trade size) holes with plugs
Break away bottom panel swings down for easy access wiring
11 gauge cold rolled steel ‘L’ brackets for stable mounting
Mounting plate and hardware included
FINISH
Brushed Stainless Steel
ELECTRICAL
Long life, high efficiency 266 degree F (130 degree C) class 'B' rated transformer core
Copper Shielded isolation/insulation; No contact between 120v and 12v windings
1500v Isolation between all windings and ground
Grade M19 electric grade steel for superior electrical and magnetic properties
Single phase, open core and coil
E.L. laminated core has concentric winding and is protected by 180 degree C thermal switch.
Double vacuumed impregnated with black slate flour
Filled varnish for superior heat dissipation and noise reduction -- Class 180 degree C
120v primary, 12.5v secondary 50/60 Hertz/cycle (standard)
6 foot 18/3 SJT-WA weatherproof grounded power cord (120v)
ON/OFF control via rocker switch on 120v side
Extra heavy duty (80 amp) terminal lugs
Manually resettable circuit breakers on front panel for overload and short circuit protection
Download PDF SpecificationShare your knowledge of this product. Be the first to write a review »
