Focus Industries WT-212-200-RPC 200 Watt Weatherproof Transformer, Twin Circuit (2 x 12.5V) with Remove Photocell

Focus Industries WT-212-200-RPC 200 Watt Weatherproof Transformer, Twin Circuit (2 x 12.5V) with Remove Photocell

10% off on $500 order or more
Price: $649.07
Price: $649.07

MODEL: Focus-WT-212-200-RPC
Add To Wishlist
Request a Quote
Ordering a large quantity? Request a quote
Find your items based on model numbers and product specification. Photo might not represent the actual item or color.

See all color options here

View full details

description

PRODUCT SPECIFICATIONS
MATERIAL/FEATURES
  • UL1838 and UL1598 Listed, the standard for low voltage landscape lighting
  • 100 to 1,200 watt output models available
  • Heavy duty extruded 6063-T6 aluminum enclosure lockable slide cover
  • Above grade, NEMA 3R rated, rain tight enclosure
  • LED indicators for instant recognition of 120v and 12v power
  • Photocell ready with quick connector
  • Mounting plate and hardware supplied for easy installation FINISH
  • Semi-gloss black polyester powder coat; optional polyester powder coat options available
ELECTRICAL
  • Long life, high temperature (130°C) Class B rated transformer core
  • Copper Shielded Isolation/Insulation type - no contact between 120 volt & 12 volt windings.
  • 1500v solation between all windings and ground
  • Grade M19 electrical grade steel for superior electrical and magnetic properties
  • Strip copper secondary windings for lower temperature rise.
  • Single phase, open core and coil
  • E.L. laminated windings (linear output) vacuum impregnated with black slate flour
  • Filled varnish for superior heat dissipation and noise reduction. Class 180 degree C
  • 120 volt primary, 12.5 volt secondary 50/60 hertz/cycle (standard)
  • 6 foot 18/3 SJT-WA weatherproof grounded power cord with flat angle plug
  • On/Off rocker switch
  • Manually Resettable magnetic circuit breaker for overload and short circuit protection
OPTIONS
  • -MV Multi-Voltage 12.5v, 13.5v, 14.5v Output (300w/600w/900w/1200w)
  • -TR Timer Ready for plug in timers supplied by others
  • -T Mechanical Timer
  • -DT Digital Timer
  • -AT Astro Timer
  • -PC Photocell
  • -RPC Remote Photocell
  • -D Full Phase/Range Dimmer
  • -R 12v & 24v VAC Relay
Note: For 220v,240v & 277v no dimmer option

WARRANTY
  • 5 year warranty on enclosure
  • 10 year warranty on mechanical/electrical components
  • 3 year warranty on all timers
