Greengate LDCM-PL-120-277-010V-GR 0-10V Linear Dimming Control Module

PRODUCT SPECIFICATIONS
Mechanical
Size: 3.4"W x 2"H x 7"L (87 mm x 50 mm x 178 mm)
Housing / Lens: Injection Molded Polycarbonate
Connectors: Lead Wire 6" From Conduit
Weight: 0.99 lbs (0.45 kg)
Environment: ETL Damp Location
Mounting: Conduit mounting from both sides

Electrical Power
Ratings:

• 450W Max @ 110-120 V
• 1000W Max @ 277V

Max Fixture Run Length: Calculate Maximum Run per LDCM unit based on the Power Consumption of the fixture used
Operating Voltage: 110VAC-120VAS, 277VAC - Auto-Sensing Voltage Switch
Operating Hertz: 60 Hz
Startup Temperature: -4°F to 104°F (-20°C to 40°C)
Operating Temperature: -4°F to 104°F (-20°C to 40°C)
Storage Temperature: -40°F to 176°F (-40°C to 80°C)
Control Requirements Dimming: 110-120VAC; ELV (reverse) - RP; converted from 0-10V
Controller 277VAC; ELV (reverse) - RP; converted from 0-10V Controller

Rating & Certifications
ETL / cETL Damp Locations

Warranty
Five year warranty standard
