Greengate WBSD-010M-C1 1200VA, 120/277 Volt AC 60Hz, Single-Pole and 3-Way Slide Dimmer, White, Ivory and Almond Faceplate Color Kit
Greengate WBSD-010M-C1 1200VA, 120/277 Volt AC 60Hz, Single-Pole and 3-Way Slide Dimmer, White, Ivory and Almond Faceplate Color Kit
Regular price
Price:
$115.09
Regular price
Price:
Sale price
$115.09
Unit price
per
MODEL: Greengate-WBSD-010M-C1
Usually Ships in 4-6 business days. Urgent Project? Contact Us
Couldn't load pickup availability
Ordering a large quantity?Request a quote
description
PRODUCT SPECIFICATIONS
Wallplate not included: This is an accessory for the Greengate Lighting Control System.
Mechanical
Wallplate not included: This is an accessory for the Greengate Lighting Control System.
Mechanical
Size: 4.2” x 2.1” x 1.8” (105mm x 54mm x 46mm)
Environment:
Color: Color change kit included (White, Ivory, Light Almond)
Housing: Injection molded housing resin complies with UL 94V-2
Connections: Screw terminals
Electrical
Power:
Environment:
- Operating temperature: 32°F to 131°F (0ºC to 55ºC)
- Relative humidity operating: non-condensing 20% to 90%
- For dry location only
Color: Color change kit included (White, Ivory, Light Almond)
Housing: Injection molded housing resin complies with UL 94V-2
Connections: Screw terminals
Electrical
Power:
- 120VAC, 1200VA, 60Hz
- 277VAC, 1500VA, 60Hz
- 10A LED @ 120/277VAC, 60Hz
- 0-10VDC: 28mA Sink Capacity
Wiring type:
Standards/Ratings- Single pole and 3-way wiring
- Class 1 or Class 2 wiring capabilities
- Works with the SP20-RD4 or directly controls the load
- cCSAus
- Five year warranty
