Halo Recessed HLCE4079301EWH-12P 4" LED Surface Disk Light, 800 Lumens, 3000K, 90 CRI, 120V, 60Hz, LE & TE Phase Cut 10% Dimming, 12 Bulk Pack
Halo Recessed HLCE4079301EWH-12P 4" LED Surface Disk Light, 800 Lumens, 3000K, 90 CRI, 120V, 60Hz, LE & TE Phase Cut 10% Dimming, 12 Bulk Pack
Regular price
Price:
$114.00
Regular price
Price:
Sale price
$114.00
Unit price
per
Ordering a large quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
Construction
Construction
- Stamped aluminum
- Precision engineered optic provides uniform luminance from a low-profile convex lens
- Removable lens for easy install from below installation
- Back lit LED technology
- Color Temperature: Available only in dedicated 3000K, 4000K, 5000K CCT
- Color Quality: 90 CRI minimum
- Color Accuracy within 6 SDCM at the CCT endpoints, provide color accuracy and uniformity
- Expected Life: L70 at 50,000 hours projected in accordance with TM-21
- Integral 120V 60 Hz constant current driver provides noise free operation
- Continuous, flicker-free dimming from 100% to 10% (See Dimming Guide for compatible dimmers)
- Continuous, flicker-free dimming from 100-10% with 120V phase cut Leading Edge (LE) and Trailing Edge (TE) dimmers.
- TIPS: For optimal dimming performance, consider dimmers with low-end trim adjustment and note that some dimmers require a neutral wire in the wallbox. (See the HLC Dimming Guide and then consult dimmer manufacturer for compatibility and conditions of use.)
Electrical Junction Box Mounting
Recessed Housing Mounting- HLCE fixtures may be used in compatible electrical junction boxes in direct contact with insulation including spray foam insulation
- Installs from below the ceiling
- Suitable for installation in most 3-1/2" and 4" octagon and round electrical junction boxes.
- Compatible with compact (pancake) junction boxes
- Installer must ensure compatibility of fit, wiring and proper mounting in the electrical junction box. This includes all applicable national and local electrical and building coded NEMA LSD 57-2013
- Extension Springs for 5" & 6" housings included in the box
- Not for use in recessed housings in direct contact with spray foam insulation refer to NEMA LSD 57-2013
- Compatible with Halo 5" and 6" housings
- Wire nuts provided for mains connections
- The included E26 medium screw-base Edison adapter provides easy retrofit of incandescent housings (non-California product only).
Compliance
Warranty- cULus certified for US and Canada
- Damp location listed
- Airtight per ASTM-E283 (no gasket necessary)
- Suitable for use in clothes closets when installed in accordance with the NEC 410.16 spacing requirements
- EMI/RFI emissions per FCC 47CFR Part 15 consumer limits
- Contains no mercury or lead and RoHS compliant*
- Photometric testing in accordance with IES LM-79-08
- Lumen maintenance projections in accordance with IES LM-80-08 and TM-21-11
- ENERGY STAR certified, reference Certified Light Fixtures database
- Certified to State of California Title 20, Stateregulated LED Lamp; reference Modernized Appliance Efficiency Database System (MAEDBS) for State-regulate d LED Lamp
- Can be used for State of California Title 24 high efficacy LED compliance under JA8*, reference Modernized Appliance Efficiency Database System (MAEDBS) for 2019 JA8 High Efficacy Lighting
- Five year limited warranty
