Halo Recessed SMD12R209SWHE 12" Round Surface Mount Downlight, 2000 Lumens, 90 CRI, Field Selectable 2700K, 3000K, 3500K, 4000K, or 5000K Color Temperature, 120-277V, Matte White
Halo Recessed SMD12R209SWHE 12" Round Surface Mount Downlight, 2000 Lumens, 90 CRI, Field Selectable 2700K, 3000K, 3500K, 4000K, or 5000K Color Temperature, 120-277V, Matte White
Regular price
Price:
$64.00
Regular price
Price:
Sale price
$64.00
Unit price
per
Ordering a large quantity?
Request a quote
description
PRODUCT SPECIFICATIONS
Housing
Housing
- Non-electrically conductive polycarbonate frame.
- High impact diffuse polystyrene lens provides shielding to the light guide with no pixilation
- Stamped aluminum housing provides thermal cooling achieving L70 at 50,000 hours in IC and non-IC applications
- Closed cell gasket achieves restrictive airflow and wet location requirements without additional caulking
- Precision acrylic light guide organizes source flux into wide distribution with 1.2 - 1.4 spacing criteria useful for general area illumination
- Mid power LED array provide a uniform source with high efficiency and long life.
- Available in 90 CRI minimum, R9 greater than 50 and color accuracy within 3 SDCM provide color accuracy and uniformity
- Integrated 120-277V 60Hz constant current driver provides noise free operation.
- SMD 12" is universal Voltage (120-277V) configurations are recommended for use with compatible 0-10V DC low voltage dimmers only.
- Adjustable spider plate allows for quick installation into both junction boxes and recessed housings.
- Torsion springs and friction blades included
- The SMD may be used in compatible electrical junction boxes in direct contact with insulation including spray foam insulation.
- Suitable for installation in many 3-1/2" and 4" square, octagon, and round electrical junction boxes.
- Note: SMD12 is only compatible with junction boxes that provide minimum depth of 2-1/8”.
- Installer must ensure compatibility of fit, wiring and proper mounting in the electrical junction box. This includes all applicable national and local electrical and building coded
- SMD skins are accessory rings in both round and square. These skins attach to the SMD for a permanent finish. Refer to the SMD accessories specification sheet for details.
Compliance
Warranty- cULus Certified for use with Halo housings and for use with other’s housings, see instruction sheet for conditions of acceptability.
- Wet and Damp Location listed, airtight per ASTM-E283
- Suitable for use in closets, compliant with NFPA 70, NEC Section 410.16 (A)(3) and 410.16 (C)(5)
- EMI/RFI emissions per FCC 47CFR Part 15B
- Contains no mercury or lead and RoHS compliant.
- Photometric testing in accordance with IES LM-79-08
- Lumen maintenance projections in accordance with IES LM-80-08 and TM-21-11.
- Can be used for State of California Title 24 high efficacy luminaire compliance, reference the California Energy Commission Title 20 Appliance Efficiency Database for current listings.
- Can be used for International Energy Conservation Code (IECC) and high efficiency luminaire compliance
- ENERGY STAR listed, reference database for current listings
- Five-year limited warranty
