Halo TGS5S401MSCB High Output LED Security Floodlight, 5800 Lumens, 4000K, Single Head Motion Sensor, 120-277V, White
Halo TGS5S401MSCB High Output LED Security Floodlight, 5800 Lumens, 4000K, Single Head Motion Sensor, 120-277V, White
Regular price
Price:
$135.55
Regular price
Price:
Sale price
$135.55
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
Construction
Electrical
Compliance and Certifications
Construction
- Durable die-cast aluminum heads suitable for wet locations
- Powder coat finish on the die-cast heads.
- Tool-less head and motion sensor adjustment
- Mounts to wall or eave on most standard 4" Round & Octagon recessed junction boxes, using two screws and mounting bracket hardware included in the box
- Quick Connect wiring harness system makes wiring simple without requiring wire nuts
- Optional Accessory Mounting plate kit used when mounting to surface-mounted junction boxes. (Sold separately.)
- Adjustable Brightness Lumen Select feature can toggle between Three outputs, low - medium - high using rotatable dial on the fixture housing
- Super Bright High Output of 5800 lumens great for residential and commercial applications.
- Wide UV resistant PC lens distributes light efficiently and won’t yellow over time
Electrical
- 120-277V Universal voltage, 60Hz Driver
- Power Factor >.90
- THD <20%
- Built to last with maintenance-free LEDs with 70,000 hours of life
- 4000K Bright white color temperature ideal for security applications
- 80CRI renders colors accurately
- Fixture operating temperature of -30°C to 40°C
- DUSK TO DAWN SKUS
- 180° detection radius up to 50’ range, with adjustable sensitivity and duration from 30 seconds - 12 minutes.
- Integral photocell allows for nighttime ON / daytime OFF operation. Photocell can be turned on or off by using rotatable cap
-
Selectable standby dimming level, when
motion no longer detected light will dim
down to a selected level and can be field
configured from 0% to 100%
- UL certified for US and Canada for wet locations
- EMI/RFI emissions per FCC 47CFR Part 15B
- Contains no mercury or lead and RoHS compliant.
- Photometric testing in accordance with IES LM-79-08 Lumen maintenance projections in accordance with IES LM-80- 08 and TM-21-11
- ICES-005(B) Intentional Radiator
- Meets CA Prop 65
- Can be used to meet Title 24 Residential and Non-Residential
- Textured Bronze/ White Finish
- Five year limited warranty,
Download PDF specification Share your knowledge of this product. Be the first to write a review »
