Hubbell Outdoor Lighting ASL1-100-4W-A 100W Area Light LED, 160 LEDs, 4000K, 70 CRI, 120-277V, Square Arm Mounting, Dark Bronze Matte Textured

Hubbell Outdoor Lighting ASL1-100-4W-A 100W Area Light LED, 160 LEDs, 4000K, 70 CRI, 120-277V, Square Arm Mounting, Dark Bronze Matte Textured

Price: $357.08
Price: $357.08

MODEL: Hubbell-ASL1-100-4W-A
Add To Wishlist
Request a Quote
Ordering a large quantity? Request a quote
View full details

description

PRODUCT FAMILY SPECIFICATIONS
CONSTRUCTION
  • Die-cast housing with hidden vertical heat fins that are optimal for heat dissipation while keeping a clean smooth outer surface
  • Corrosion resistant, die-cast aluminum housing with powder coat paint finish
  • Separate optical and electrical compartment for improved thermal management and optimum component operation
  • TGIC thermoset polyester powder paint finish applied at nominal 2.5 mil thickness
OPTICS
  • Entire optical aperture illuminates to create a larger luminous surface area resulting in a low glare appearance without sacrificing optical performance
  • Premium engineered individual acrylic lenses deliver IES Type 3 and 4W distributions
  • Lens distributions are field rotatable (in 90˚ increments) or exchangeable for job site fine-tuning
  • 4000K (70 CRI) CCT
  • 160 midpower LEDs
  • Zero uplight at 0 degrees of tilt
INSTALLATION
  • Arm mounting block with S2 drill patterns
  • Fixture ships with slotted mounting block to accommodate wide range of drill patterns for easy retrofit opportunities
  • Mast arm fitter accessory or option available for 2-3/8” OD brackets with vertical tilt of +3°, 0° or -3°
ELECTRICAL
  • Universal 120-277 VAC input voltage, 50/60 Hz
  • Ambient operating temperature -40˚ C to 40˚ C
  • Drivers have greater than 90% power factor and less than 20% THD
  • LED drivers have output power over-voltage, over-current protection and short circuit protection with auto recovery
  • Built in driver surge protection of 6kV.
CONTROLS
  • 0-10 Volt Dimmable Driver Standard controls
CERTIFICATIONS
  • Listed to UL1598 and CSA C22.2#250.0-24 for wet locations and 40˚C ambient temperatures
  • 1.5G rated for ANSI C136.31 high vibration applications
  • IP65 optical assembly
  • DLC (DesignLights Consortium Qualified), with some Premium Qualified configurations. Not all product variations on this page are DLC Qualified. Refer to http://www.designlights.org for the most up-to-date list.
WARRANTY
  • 5 Year warranty
