Hubbell Lighting Outdoor LNC2-48L-25-5K7-3-UNV-DBT Laredo 25W LED Compact Wallpack, Full Cut Off, 5000K, Type III, 120-277V, Dark Bronze Matte Textured

Hubbell Lighting Outdoor LNC2-48L-25-5K7-3-UNV-DBT Laredo 25W LED Compact Wallpack, Full Cut Off, 5000K, Type III, 120-277V, Dark Bronze Matte Textured

Price: $539.19
Price: $539.19

MODEL: Hubbell-LNC2-381
Add To Wishlist
Request a Quote
Ordering a large quantity? Request a quote
View full details

description

PRODUCT FAMILY SPECIFICATIONS
CONSTRUCTION
  • Rugged die-cast aluminum housing protects components and provides an architectural appearance
  • Casting thermally conducts LED heat to optimize performance and long life
  • Powder paint finish provides durability in outdoor environments. Tested to meet 1000 hour salt spray rating.
  • Construction tested to ASTM B117 for 1,000 hours of salt spray.
OPTICS
  • Zero uplight distributions using individual acrylic Micro Strike Optics
  • LED optics provide IES type III and IV distributions. Optional (CS) acrylic diffuser available for reduced glare
  • L96 at 60,000hrs (Projected per IESNA TM-21-11), see table on page 3 for all values
INSTALLATION
  • Quick-mount adapter provides easy installation to wall or to recessed junction boxes (4" square junction box)
  • Designed for direct j-box mount.
  • Optional 1/2” conduit hubs available (standard for control options and battery versions)
ELECTRICAL
  • 120V-277V universal voltage 50/60Hz 0-10V dimming drivers
  • 347V and 480V dimmable driver option available in 25W and 35W configurations
  • Minimum operating temperature is -40˚C/-40˚F
  • Drivers have greater than .90 power factor and less than 20% Total Harmonic Distortion
  • Driver RoHS and IP66
  • 10kA surge protector available as an option
  • 3000K CCT nominal, 4000K CCT nominal, 5000K CCT nominal (70 CRI)
CONTROLS
  • Universal button photocontrol for use with 120-277V configurations
  • Occupancy sensor options available for complete on/off and dimming control
  • NX Lighting Controls available that feature dimming and occupancy sensor
  • Integral Battery Backup provides emergency lighting for the required 90 minute path of egress. Uses 15 watts of power for about 2000 lumens
  • Dual Driver option provides 2 drivers within luminaire but only one set of leads exiting the luminaire, where Dual Power Feed provides two drivers which can be wired independently as two sets of leads are extended from the luminaire. Both options can not be included in one fixture.
CERTIFICATIONS
  • Listed to UL1598 and CSAC22.2#250.0-24 for wet locations
  • DLC (DesignLights Consortium Qualified), with some Premium Qualified configurations. Not all product variations on this page are DLC Qualified.
  • Fixture is IP65 rated
WARRANTY
  • 5 year warranty
