Hubbell Outdoor Lighting PGM3-150P-18-BZ 150W Perimaliter Pulse Start Metal Halide Wallpack, Quad Tap Voltage, HX-HPF Ballast, Lamp Not Included, Medium Base

Product Description

• Perimeter lighting for safety and security. High performance with wide lateral spread

Product Specifications

• Cast aluminum door frame with prismatic glass refractor. Door seals to housing gasket with twin Hubbell Gard captive fasteners
• Die cast aluminum housing allows firm mounting over recessed junction boxes or on flat surfaces for 1/2” surface conduit. Casting dissipates ballast heat for long life. Top hub supplied for field installation of button photo control, ordered separately
• Specular aluminum reflector with kicker panels drive maximum lamp lumens to the refractor prisms. Vertical socket position with these optics provide six to one spacing to mounting height ratio for maximum spacing or better uniformity, greater lumens and lamp life
• PGM features 70-250w HPS and pulse start metal halide. QuadTap, 347V and 50Hz 220/240V available. Many listings include lamp for contractor convenience; see standard selections in Ordering Information below.
• Dark bronze 800 Series powder paint finish standard on frame and housing.

Certifications

• UL
• Wet listed

Ordering Information
