Invue MSA-SA1C-740-U-T3-BK Decorative LED Area Light, 1 Square, 1050mA, 70 CRI, 4000K, 120-277V, Type III Distribution, Black
Invue MSA-SA1C-740-U-T3-BK Decorative LED Area Light, 1 Square, 1050mA, 70 CRI, 4000K, 120-277V, Type III Distribution, Black
Regular price
Price:
$1,879.35
Regular price
Price:
Sale price
$1,879.35
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
Construction
Construction
- Die-cast aluminum main housing and permanent mold spider mount base maintain a minimum Ø.125" wall thickness
- Integral aluminum heat sink provides superior thermal performance, enabling use in +40°C ambient with optional 50°C environments
- Top mounted door assembly, heavy wall, diecast aluminum door maintains a nominal Ø.125 thickness
- Door includes a 4.5" stainless steel safety tether standard or an optional self-retaining interior hinge
- Continuous silicone gasket provided to seal housing door assembly and optic tray
- Four inset fasteners on underside of housing provide access to luminaire interior
- 17 patented AccuLED high efficiency roadway and area optical distributions
- 3 shielding options for spill light control; available factory-installed or as field-installed accessory
- LED drivers mount to die-cast aluminum back housing for optimal heat sinking, operation efficacy, and prolonged life
- Standard drivers feature electronic universal voltage (120-277V 50/60Hz), 347V 60Hz or 480V 60Hz operation, greater than 0.9 power factor, less than 20% harmonic distortion
- 10kV surge protection provided standard
- Occupancy sensor and dimming options available
- Fitter assembly mounts over 3" O.D. Tenon via four concealed, steel set screws and jam-setscrews
- 1.5G vibration rated standard; option for 3G rated
- Housing is finished in five-stage super TGIC polyester powder coat paint, 2.5 mil nominal thickness for superior protection against fade and wear. Coastal construction option available.
- Lightsquares cover plates are standard white and may be specified to match finish of luminaire housing
- RAL and custom color matches available
- Additional charges and lead time apply
- Lightsquares feature an IP66 enclosure rating
- Available in Costal Construction, salt spray tested to over 5,000-hours per ASTM B117, with a scribe rating of 9 per ASTM D1654
- Housing and optics IK10 impact rated
- IDA Certified 3000K CCT and warmer only
- cULus listed for use in -40°C to 50° environments
- BAA domestic preference option meets BAA requirements. See DOMESTIC PREFERENCES website or consult the CLS Domestic Preferences team for more information
- Products that meet BABA through Exemption (BABAE): This exception allows any product to satisfy BABA requirements regardless of domestic content manufacturing for projects funded by FHWA through Oct 1st 2025.
- Products that meet BABA through BAA Exemption (BABAF): FHWA and FTA agencies are utilizing their BAA rules for BABA compliance. Cooper’s products with a BAA designation are manufactured in the US and utilize a BAA COTS exemption rule for compliance. To verify a configured product with specificaccessories and options meet BABA Domestic Preference Requirements; submit this catalog number to Cooper Lighting Quotation team for validation by our Engineering and Manufacturing teams.
- Please refer to the DOMESTIC PREFERENCES website or consult the CLS Domestic Preferences team for more information
- Components shipped separately may be separately analyzed under domestic preference requirements
- Five year limited warranty
