Isolite EXP-AC-G-1W-MB-AB 2.3W Explosion Proof LED Exit Sign, 120-277V, Green Illumination, Single Face, White Background, Back Mount, Double Arrow

Isolite EXP-AC-G-1W-MB-AB 2.3W Explosion Proof LED Exit Sign, 120-277V, Green Illumination, Single Face, White Background, Back Mount, Double Arrow

Price: $2,392.50
Price: $2,392.50

MODEL: Isolite-EXP-255
Add To Wishlist
Request a Quote
Ordering a Large Quantity? Request a quote
View full details

description

PRODUCT FAMILY FEATURES
  • Illumination 4X brighter than UL 924 requirement with super-bright, long-life LEDs that have a 25+ year life expectancy.
  • Premium long-life, high-temperature fused nickel cadmium battery with standard UL listed 3-hour run time.
  • Standard battery diagnostic system monitors battery status, detects cell failure, and issues an alert when there’s reduced capacity, indicating the need to replace the battery.
  • Line-latch prevents unnecessary discharge of battery during installation. Loads will not illuminate until after application of utility power.
  • Brownout detection ensures emergency operation during periods of low line voltage.
  • Sealed external momentary test switch and dual diagnostic LED indicator displays AC presence and Hi-Charge status.
  • Self-Test/Self-Diagnostic monitoring available.
  • Zero current low-voltage disconnect used to prevent battery from being overly discharged.
  • Unique electronic driver circuit provides current control and protection, ensuring optimum LED efficiency and life.
  • 120/277 VAC with field selectable inputs.
PRODUCT FAMILY SPECIFICATIONS
CONSTRUCTION
  • Precision die-cast aluminum housing with a flawless, laser-formed acrylic legend.
INPUT POWER
  • AC models: Red 1.5W; Green 2.3W
  • EM models: Red 2.5W; Green 3.0W
LETTERS
  • 6” high; 0.75” stroke
ARROWS
  • NFPA-type, universal field installable, selfadhesive chevrons.
TEMPERATURE RATING
  • Green: From 50°F to 104°F
  • Red: From 50°F to 131°F
APPROVALS
  • Class I, Div 1 Groups C & D
  • Class I, Div 2 Groups A, B, C & D
  • Class II, Div 1 Groups E, F & G
  • Class III, Div 1
  • Class I, Zone 1, Groups IIA, IIB
  • Class I, Zone 2, Groups IIA, IIB + H2 & IIC
  • Temperature Class (T-Rating) - T6
  • UL 924
  • NFPA 101 Life Safety Code
  • NFPA 70-NEC
  • OSHA
  • IP65
  • CEC Title 20 Compliant
  • UL 1598A -- Marine Outside Type
  • UL 844
  • BAA Compliant
WARRANTY
  • Isolite offers a 5-year limited warranty.
