Isolite LPDC2-AC-R-1-BK-BK-MTEB 5W Die-Cast Aluminum LED Exit Sign, AC Only, Red Illumination, Black Face, Black Bpdy, Top/End/Back Mount
Isolite LPDC2-AC-R-1-BK-BK-MTEB 5W Die-Cast Aluminum LED Exit Sign, AC Only, Red Illumination, Black Face, Black Bpdy, Top/End/Back Mount
Regular price
Price:
$259.05
Regular price
Price:
Sale price
$259.05
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
CONSTRUCTION
CONSTRUCTION
- Injection-molded reflector ensures easy installation, maintenance, and even illumination.
- Heavy-duty, three-piece die-cast aluminum housing with a removable front stencil and light seal.
- Sleek 2.5" profile with softened corners and chamfered edges.
- Optional polycarbonate face shield, tamper-proof screws, swivel pendant, and specialty mounts. See wet location spec sheet.
- 6.0" high; 0.75" stroke
- NFPA type, universal field selectable chevrons.
- 100 foot visibility rating
- 50ºF to 104ºF (10º C to 40ºC)
- Low-profile universal canopy with 0.75" cast nipple and locking nuts.
- AC models: 3.24W
- EM models: 4.08W
- UL 924 Listed to 100ft Visibility Distance
- CSA C22.2 No. 141-10
- CEC Title 20 Compliant
- NFPA 101 Life Safety Code
- NFPA 70-NEC
- OSHA
- NEMA 4X (See Wet Location)
- BAA Compliant
- Isolite offers a 5-year limited warranty. For further details, refer to General Warranty and Obligations in the Isolite manual or on our website.
- The EEW option extends the electronics warranty to 10 years.
- Batteries are not included in the extended warranty.
