Juno Aculux AX2 D 12LM 27K 80CRI 45D FPC 120 Recessed Lighting 2 inch LED New Construction Standard Housing 1000 Lumens, 2700K Color Temperature, 80 CRI, Wide Flood Beam, 120V Dimmable Light
Juno Aculux AX2 D 12LM 27K 80CRI 45D FPC 120 Recessed Lighting 2 inch LED New Construction Standard Housing 1000 Lumens, 2700K Color Temperature, 80 CRI, Wide Flood Beam, 120V Dimmable Light
Email or call us at 310-822-6500 for pricing
For project,
request a quote
description
Product Family Description
LED Light Engine
- Recessed LED downlight luminaire with 2? round aperture delivers up to 1040 lumens and is available with optical distributions approximating that of MR16 halogen lamps.
- Fixture has 50? visual cut-off for low aperture brightness.
- Low profile housing is available in IC rated or non-IC rated configurations.
LED Light Engine
- Consistent fixture to fixture color consistency within a 2-step MacAdam ellipse
- 2700K, 3000K, 3500K, or 4000K color temperatures are available with 80 CRI minimum
- 2700K and 3000K also available with 90 CRI minimum.
- Available with field interchangeable optics in 18? Spot, 24? Narrow Flood, 35? Flood, and 45? wide flood distributions.
- Self Flanged and Flush Mount styles are available
- For flush mount installations in drywall ceilings, specify the FMA2 adapter
- For flush mount installations in solid ceiling materials such as wood, stone, or tile ceilings, no flush mount adapter is required.
- Choice of two drivers to accommodate voltages from 120-277 volts AC at 50/60Hz
- Dedicated 120V (-1) driver is dimmable with most incandescent, magnetic low voltage, and electronic low voltage dimmers
- Universal Voltage (-U) driver is dimmable with most 0-10V protocol dimmers
- For a list of compatible dimmers, refer to ACLXLED2-DIM
- Power Factor > 0.9
- Field replaceable from above or below ceiling.
- Rated for 50,000 hrs at 70% lumen maintenance.
- 5 years from date of purchase on LED components
- Standard Juno Lighting Group product guarantee terms and conditions apply.
- UL and cUL listed for damp or wet locations depending on trim
- IC rated new construction fixture meets energy code Air Leakage requirements per ASTM E283
- ENERGY STAR? Qualified with select color temperatures and trims
- IC rated luminaires with 3000K, 90 CRI light engine are certified to high efficacy requirements of California T24 with select trims
- IC rated new construction luminaire is Chicago Plenum (CCEA) approved
- Union made.
