PRODUCT DESCRIPTION

Recessed adjustable MR16 remodel luminaire with 3¼” aperture. Fixture has 50° visual cutoff to lamp and lamp image. Low profile non-IC housing is for use in non-insulated areas, or where insulation is spaced at least 3” from housing. Installs quickly and securely with patented (US Patent 7,191,993) push-pull cable system through ceiling opening.

PRODUCT SPECIFICATIONS

Trims Style

Utilizes torsion spring retention for tight, secure fit to ceiling

Trim ring features beveled knife edge for clean ceiling interface.

Lens

Lamp holder accommodates up to three (3) 2” captive accessory lenses
Supplied with stippled clear uniformity lens.

Socket

Ceramic bi-pin socket with double blade nickel alloy contacts
Aluminum heat shield.

Lamp

One 50W MR16 lamp max. (See trim for max. lamp rating)

Adjustability

Optimized lamp beam optics insures maximum light output and low brightness at any angle
361° rotation (350° with mechanism, up to 18° additional with rotation of housing assembly) and 35° tilt hot aiming
Black adjustment mechanism preserves dark aperture.

Transformer

120 V thermally protected magnetic transformer is serviceable from below ceiling
High efficiency (>95%), high power factor electronic transformer also available.

Dimming

May be dimmed using dimmers specifically designed for low voltage magnetic or electronic transformers; consult factory or dimmer manufacturer for additional information.

Codes/Labels

UL and cUL listed for through-branch wiring, damp locations (wet location with approved trims)
Product thermally protected
Union made.

Patented (US Patent 7,191,993) “ Push-Pull” Cable System

Allows rapid installation without tools or loose parts
Template included for accurate ceiling cutout
Housing accommodates ceiling thickness from 3/8” to 2” without altering photometrics
Fits 2 x 6 construction.

Junction Box

Rated for 4 No. 12 AWG 90° C through branch circuit conductors and includes (3) ½”, and (2) Non-metallic sheathed cable knock-outs
Push-in electrical connectors for field connections.

Housing/Mounting
