Home > Juno Lighting > Juno IC1LED G4 14LM 30K 90CRI 120 FRPC Recessed Lighting 4" IC LED New Construction Housing, Generation 4, 1400 Lumens, 3000K Color Temperature, 90 CRI, 120V Forward/Reverse Phase Cut, 5% Dim
Juno IC1LED G4 14LM 30K 90CRI 120 FRPC Recessed Lighting 4" IC LED New Construction Housing, Generation 4, 1400 Lumens, 3000K Color Temperature, 90 CRI, 120V Forward/Reverse Phase Cut, 5% Dim
Juno IC1LED G4 14LM 30K 90CRI 120 FRPC Recessed Lighting 4" IC LED New Construction Housing, Generation 4, 1400 Lumens, 3000K Color Temperature, 90 CRI, 120V Forward/Reverse Phase Cut, 5% Dim
Regular price
Price:
$136.74
Regular price
Price:
Sale price
$136.74
Unit price
per
MODEL: Juno-IC1LED-31287
Usually Ships in 3-5 business days. Urgent Project?
contact us >>
Couldn't load pickup availability
Ordering a Large Quantity?
Request a quote
description
PRODUCT DESCRIPTION
Dedicated LED, Air-Loc sealed new construction housing with integral light engine. Double wall, shallow housing construction allows for fit in 2 x 6 construction. Can be completely covered with insulation. Fully sealed housing stops infiltration and exfiltration of air, reducing heating and air cooling costs without the use of additional gaskets. LED housing is designed to provide 50,000 hours of life and is compatible with many standard Juno trims. 5 year limited warranty on LED components.
PRODUCT SPECIFICATIONS
LED Light Engine
LED Driver
Dedicated LED, Air-Loc sealed new construction housing with integral light engine. Double wall, shallow housing construction allows for fit in 2 x 6 construction. Can be completely covered with insulation. Fully sealed housing stops infiltration and exfiltration of air, reducing heating and air cooling costs without the use of additional gaskets. LED housing is designed to provide 50,000 hours of life and is compatible with many standard Juno trims. 5 year limited warranty on LED components.
PRODUCT SPECIFICATIONS
LED Light Engine
- LED array attached to high purity aluminum, thermally conductive inner housing provides superior heat transfer to ensure long life of the LED
- Replaceable light engine mounts directly to inner housing assembly
- Replaceable light engine mounts directly to inner housing assembly and incorporates the latest generation, high lumen output LED array
- LEDs are binned within a 3-step MacAdam Ellipse exceeding ENERGY STAR requirements for superior fixture to fixture color uniformity
- 2700K, 3000K, 3500K, or 4000K color temperatures available
- 90 CRI minimum.
- Choice of dedicated 120 volt (120) driver or universal voltage (MVOLT) drivers that accommodate input voltages from 120-277 volts AC at 50/60Hz
- Power factor > 0.9 at 120V input
- 120 volt only driver is dimmable with the use of most incandescent, magnetic low voltage and electronic low voltage wall box dimmers
- Universal voltage drivers are dimmable with the use of most 0-10V wall box dimmers
- For a list of compatible dimmers, see JUNOICLED-DIM
- Mounted inside housing for easy access from below ceiling.
Life Rated for 50,000 hours at 70% lumen maintenance.
Labels- ENERGY STAR Certified when used with select trims
- Certified to the high efficacy requirements of California T24 JA8-2016 with select trims
- UL listed for U.S. and Canada through-branch wiring, damp location
- Union made
- UL and cUL
- CP option is compatible with spray foam insulation with an R-value of 3.2 per inch or less.
downloads
Download PDF SpecificationShare your knowledge of this product. Be the first to write a review »
