Home > Juno Lighting > Juno IC1LED G4 06LM 35K 90CRI MVOLT EZ1 Recessed Lighting 4" LED IC New Construction Downlight, Generation 4, 600 Lumens, 3500K, 90 CRI, 45 Degrees Medium Flood, 120-277V, 0-10V, 1% Dim
Juno IC1LED G4 06LM 35K 90CRI MVOLT EZ1 Recessed Lighting 4" LED IC New Construction Downlight, Generation 4, 600 Lumens, 3500K, 90 CRI, 45 Degrees Medium Flood, 120-277V, 0-10V, 1% Dim
Juno IC1LED G4 06LM 35K 90CRI MVOLT EZ1 Recessed Lighting 4" LED IC New Construction Downlight, Generation 4, 600 Lumens, 3500K, 90 CRI, 45 Degrees Medium Flood, 120-277V, 0-10V, 1% Dim
Regular price
Price:
$279.59
Regular price
Price:
Sale price
$279.59
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
LED Light Engine
LED Light Engine
- LED array attached to high purity aluminum, thermally conductive inner housing provides superior heat transfer to ensure long life of the LED
- Replaceable light engine mounts directly to inner housing assembly and incorporates the latest generation, high lumen output LED array
- LEDs are binned within a 3-step MacAdam Ellipse
- 2700K, 3000K, 3500K, or 4000K color temperatures available
- 90 CRI minimum.
- Two field interchangeable optics available in medium flood (45° beam angle) and wide flood (65° beam angle)
- Computer-optimized reflector design with high reflectance finish coupled with a high transmission diffusing lens conceals the LEDs and produces uniform aperture luminance.
- Compatible with wide selection of existing Juno trims
- Shadow free, knife edge design blends seamlessly into ceiling.
- Trims are wet location approved for covered ceiling applications.
- Choice of dedicated 120 volt (120) driver or universal voltage (MVOLT) drivers that accommodate input voltages from 120-277 volts AC at 50/60Hz
- Power factor > 0.9 at 120V input
- 120 volt only driver is dimmable with the use of most incandescent, magnetic low voltage and electronic low voltage wall box dimmers
- Universal voltage drivers are dimmable with the use of most 0-10V wall box dimmers
- For a list of compatible dimmers, see JUNOICLED-DIM
- Mounted inside housing for easy access from below ceiling.
Life
Rated for 50,000 hours at 70% lumen maintenance.
LabelsRated for 50,000 hours at 70% lumen maintenance.
- Can be used to comply with 2019 Title 24, Part 6, JA8 high efficacy LED light source requirements with select trims
- UL listed for U.S. and Canada through-branch wiring, wet locations (covered ceilings)
- Union made
- UL and cUL
- CP option is compatible with spray foam insulation with an R-value of 3.2 per inch or less.
Download PDF SpecificationShare your knowledge of this product. Be the first to write a review »
