Juno Recessed Lighting IC1RLEDG3-35K-U 4" LED IC Type Remodel Housing 600 Lumens, 3500K Color Temperature, Universal Driver 120-277V

Description

Dedicated 45" LED remodel housing with integral 14.6W or 16W nominal light engine, with choice of dimmable drivers: dedicated 120 volt driver or universal 120V-277V driver. 2700K. 83 CRI typical. Shallow, IC housing designed for use in 2x6 IC or non-IC construction. Ceiling cutout 4 3/8" dia.

Features & Benefits

• Dedicated LED, Air-Loc® remodel housing with integral light engine
• Shallow housing allows for fit in 2 x 6 construction
• IC remodel housing for remodel application where back side of ceiling is not accessible
• Installs through an opening in the ceiling from below
• Secured in place by factory installed remodel springs
• Can be completely covered with insulation
• LED housing is designed to provide 50,000 hours of life and is compatible with many standard Juno trims
• 5 year limited warranty on LED components.


LED Light Engine	LED array attached to high purity aluminum, thermally conductive housing and heat sink provides superior heat transfer to ensure long life of the LED Replaceable light engine mounts directly to housing assembly and incorporates the latest generation, high lumen output LED array LEDs are binned to standards that exceed ENERGY STAR® requirements yielding superior fixture to fixture color uniformity 2700K, 3000K, 3500K, or 4100K color temperatures available 83 CRI typical.
Optical System	Computer-optimized reflector design with high reflectance finish coupled with a high transmission diffusing lens conceals the LEDs and produces uniform aperture luminance Deep regression of lens produces a low glare, efficient system that can produce over 600 lumens with select trims using less than 11W (Nominal input wattage @ 120-volt operation with dedicated 120-volt driver under stable operating conditions.)
Aesthetic Trim Selections	Compatible with wide selection of existing Juno trims Shadow free, knife edge design blends seamlessly into ceiling.
LED Driver	Choice of dedicated 120 volt driver or universal voltage driver that accommodates input voltages from 120-277 volts AC at 50/60Hz Power factor > 0.9 at 120V input 120 volt only driver is dimmable with the use of most incandescent, magnetic low voltage and electronic low voltage wall box dimmers Universal voltage driver is dimmable with the use of most 0-10V wall box dimmers Mounted on the j-box for easy access and cool operation.
Life	Rated for 50,000 hours at 70% lumen maintenance.
Labels	ENERGY STAR® qualified to luminaires V1.1 requirements when used with select trims Certified to the high efficiency requirements of California T24-2008 with select trims UL listed for U.S. and Canada damp locations Union made UL and cUL.
Housing	Designed for use in IC (insulated ceiling) or non-IC construction luminum housing sealed for Air-Loc® compliance Remodel springs accommodate up to 1 1⁄2” ceiling thickness.
Junction Box	Pre-wired junction box provided with (5) 1⁄2” knockouts, (4) knockouts for 12/2 or 14/2 NM cable and ground wire Knockouts equipped with pryout slots Quick connect electrical connectors supplied as standard for fast, secure installation.
