Juno Recessed Lighting IC20RLEDG4-27K-U 5" LED IC Type Remodel Housing 600 Lumens, 2700K Color Temperature, Universal Driver 120-277V
Juno Recessed Lighting IC20RLEDG4-27K-U 5" LED IC Type Remodel Housing 600 Lumens, 2700K Color Temperature, Universal Driver 120-277V
Regular price
Price:
$233.33
Regular price
Price:
Sale price
$233.33
Unit price
per
MODEL: Juno-IC20RLEDG4-27K-U
Usually Ships in 3-5 business days. Urgent Project?
contact us >>
Couldn't load pickup availability
free shiping
details >>
Ordering a large quantity?
Request a quote
When ordering this fixture, you will get the newest generation. Different generations cannot be mixed.
description
PRODUCT DESCRIPTION
- Dedicated LED, Air-Loc® remodel housing with integral light engine
- Shallow housing allows for fit in 2 x 6 construction
- IC remodel housing for remodel application where back side of ceiling is not accessible
- Installs through an opening in the ceiling from below
- Secured in place by factory installed remodel springs
- Can be completely covered with insulation
- When used with supplied ALG kit, stops infiltration and exfiltration of air, reducing heating and air cooling costs
- LED housing is designed to provide 50,000 hours of life and is compatible with many standard Juno trims
- 5 year limited warranty on LED components.
ENVIRONMENTALLY FRIENDLY, ENERGY EFFICIENT
- No harmful ultraviolet or infrared wavelengths
- No lead or mercury
- Comparable light output to 65W BR30 incandescent
PRODUCT SPECIFICATIONS
LED Light Engine - LED array integrated to thermally conductive housing provides uninterrupted heat transfer to ensure long life of the LED
- Replaceable light engine mounts directly to housing and incorporates the latest generation, high lumen output LED array
- LEDs are binned within a 3-step MacAdam Ellipse exceeding ENERGY STAR® requirements for superior fixture to fixture color uniformity
- 2700K, 3000K, 3500K, or 4100K color temperatures available
- 90 CRI minimum.
- Computer-optimized reflector design with high reflectance white finish coupled with a high transmission diffusing lens conceals the LEDs and produces uniform aperture luminance
- Deep regression of lens produces a low glare, efficient system that can produce over 600 lumens with select trims using less than 12W*
- Wide flood distribution shipped as standard with optional optic accessories available and sold separately.
- Compatible with wide selection of existing Juno trims
- Shadow free, knife edge design blends seamlessly into ceiling.
- Choice of dedicated 120 volt driver or universal voltage driver that accommodates input voltages from 120-277 volts AC at 50/60Hz
- Power factor > 0.9 at 120V input
- 120 volt only driver is dimmable with the use of most incandescent, magnetic low voltage and electronic low voltage wall box dimmers
- Universal voltage driver is dimmable with the use of most 0-10V wall box dimmers
- For a list of compatible dimmers, see JUNOICLED-DIM
- Mounted between the j-box and housing for easy access and cool operation.
- Rated for 50,000 hours at 70% lumen maintenance.
- ENERGY STAR® Qualified when used with select baffle and cone trims
- Certified to the high efficacy requirements of California T24 with select trims
- UL listed for U.S. and Canada through-branch wiring, damp locations
- Union made
- UL and cUL.
- All reports are based on published industry procedures; field performance may differ from laboratory performance.
Product specifications subject to change without notice.
HOUSING FEATURES
HOUSING FEATURES
Housing
- Designed for use in IC (insulated ceiling) or non-IC construction
- Aluminum housing sealed for Air-Loc® compliance when used with ALG kit
- Remodel springs accommodate up to 11⁄8” ceiling thickness.
Junction Box
- Pre-wired junction box provided with (5) 1⁄2” knockouts,(4) knockouts for 12/2 or 14/2 NM cable and ground wire
- Knockouts equipped with pryout slots
- Quick connect electrical connectors supplied as standard for fast, secure installation.
