Juno Aculux INIT3SQ AR 12LM 27K 90CRI 18D FPC 120 Recessed Lighting 3" Square Remote Adjustable Housing, 1200 Lumens, 2700K, 90 CRI, 18 Degree Beam, Phase Cut Dimming & 0-10V, 120V

Juno Aculux INIT3SQ AR 12LM 27K 90CRI 18D FPC 120 Recessed Lighting 3" Square Remote Adjustable Housing, 1200 Lumens, 2700K, 90 CRI, 18 Degree Beam, Phase Cut Dimming & 0-10V, 120V

Price: $140.13
Price: $140.13

MODEL: Juno-INIT3SQ-AR-31567

Usually Ships in 3-5 business days. Urgent Project? contact us >>
Add To Wishlist
Request a Quote
Ordering a large quantity? Request a quote
View full details

description

PRODUCT DESCRIPTION
Aculux Initia 3-inch LED Remodel is an affordable precision recessed luminaire offering elegance and performance in 3 lumen packages (ranging from 400-1200 delivered lumens). Available in both ICAT and non-ICAT configurations, this recessed adjustable features field-interchangeable optics available in 4 distributions (18 degree- 50 degree) and 359 degree rotation, 35 degree tilt hot aiming. Aculux Initia adjustable housing is compatible with Initia adjustable trims which provide excellent below ceiling aesthetics that coordinate with the AX3 family.

PRODUCT SPECIFICATIONS
FIELD INTERCHANGEABLE LED LIGHT ENGINE
  • <2SDCM Binning
  • 2700K | 3000K | 3500K | 4000K CCT
  • 80+ CRI available for all CCTs
  • 90+ CRI available for 2700K & 3000K
  • Future proof and easy to maintain - serviceable from below the ceiling
OPTICAL SYSTEM
45 degree visual cutoff to source and source image
  • Field interchangeable TIR optics from 18 degree FWHM to 50 degree FWHM provide smooth, striation-free beams
  • Accommodates 2 beam control lenses or filters
    • TOOL-FREE AIMING
    359 degree horizontal, 35 degree vertical aiming
  • Numeric indicator marks allow contractor to pre-aim fixtures
    • HIGH QUALITY TRIMS
    Available with die cast bevels, pinholes, and angle cut reflectors
  • Flanged and flangeless for gypsum
  • Must specify NT3SQFMA for gypsum flangeless installation
    • FIELD REPLACEABLE DRIVER
    Accommodates 120-277V input and multiple control protocols
  • Dims without perceived flicker to <1% depending on driver specified
  • Field replaceable from below the ceiling
  • >0.9 Power Factor
    • WARRANTY & RATED LIFE
    LED is rated for >50,000 hours at 70% lumen maintenance
  • 5- year limited warranty.
    • EMERGENCY BATTERY
    Provides a minimum of 400 lumens (3000K, 80CRI) for minimum duration of 90 minutes.
  • Above ceiling access required.
  • Supplied with remote test switch
  • CEC T20 Compliant
    • CEILING THICKNESS
    • Accommodates 1/2" to 1 1/2" ceiling thickness
    INSTALLATION
    • New construction or remodel (install from below) are available.
    • Residential style bar hanger provided with all new construction housings except when specified with emergency battery.
    • Vertically adjustable mounting brackets (butterfly brackets) are provided on non-ICAT new construction housings.
    JUNCTION BOX
    • New construction housings are rated for (4) No. 12 AWG 90°C through branch circuit conductors (excludes ECOS2 & ECOD drivers)
    • New Construction housings include (6) 1/2", (1) 3/4", (4) Nonmetallic sheathed cable knock-outs.
    • Remodel housings feature (8) 1/2" knockouts suitable for daisy chain wiring.
    • Push-in electrical connectors for field connections.
    CODES & LABELS
    • UL & cUL listed for through branch wiring (excludes ECOS2 & ECOD), damp location. Listed for wet location with WSOL option
    • ICAT meets energy code air leakage requirements per ASTM E283
    • ENERGY STAR certified (excludes NT3SQAPIN)
    • Title 24, Part 6: JA-8 Compliant with 90CRI (excludes NT3SQAPIN)
    • ICAT housings are rated for direct contact with insulation
    • Low Density Spray Foam Insulation Compatible: 04LM|08LM (ICAT option) are compatible with foam insulation with an R-Value of 4.3 per inch or less (excludes ECOS2 & ECOD)
    • Union made
    A+ CAPABLE LUMINAIRE
    • This item is an A+ capable luminaire, which has been designed and tested to provide consistent color appearance and out-of-the-box control compatibility with simple commissioning.
    • All configurations of this luminaire meet the Acuity Brands' specification for chromatic consistency
    • This luminaire is part of an A+ Certified solution for nLight control networks when ordered with drivers marked by a shaded background on ordering information
