Juno L4 17LM 50K MVOLT G4 90CRI EZB WPR WH WET Indy 4" Round New Construction LED Housing, 1700 Lumens, 5000K, 120-277V, Gen 4, 90 CRI, eldoLED 0-10 SOLOdrive, Parabolic Wide Trim, White Finish, White Flange, Wet Location
Juno L4 17LM 50K MVOLT G4 90CRI EZB WPR WH WET Indy 4" Round New Construction LED Housing, 1700 Lumens, 5000K, 120-277V, Gen 4, 90 CRI, eldoLED 0-10 SOLOdrive, Parabolic Wide Trim, White Finish, White Flange, Wet Location
Regular price
Price:
$604.66
Regular price
Price:
Sale price
$604.66
Unit price
per
Ordering a large quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
Atrius-Ready Product: Select models of the L-series product line deliver valuable data and connectivity to the Atrius IoT location based platform services. For more information, please refer to www.acuitybrands.com/Atrius.
OPTICS
Hyperbolic: Patented hyperbolic shape (U.S. Patent No. 10,670,227 B2) optimized for small, directional LED source, maximizes fixture efficiency while creating the "Silent Ceiling" appearance by reducing lamp image and aperture brightness
Geometry of hyperbolic curve provides unique aperture appearance and smoother light distribution
Parabolic/Lens: Computer-optimized parabolic reflector with frosted convexed lens regressed into cone provides uniform distribution with no striations
Atrius-Ready Product: Select models of the L-series product line deliver valuable data and connectivity to the Atrius IoT location based platform services. For more information, please refer to www.acuitybrands.com/Atrius.
OPTICS
Hyperbolic: Patented hyperbolic shape (U.S. Patent No. 10,670,227 B2) optimized for small, directional LED source, maximizes fixture efficiency while creating the "Silent Ceiling" appearance by reducing lamp image and aperture brightness
Geometry of hyperbolic curve provides unique aperture appearance and smoother light distribution
Parabolic/Lens: Computer-optimized parabolic reflector with frosted convexed lens regressed into cone provides uniform distribution with no striations
Wall Wash: Available in Hyperbolic and Parabolic. Both providing uniform distributions with no striations
ELECTRICAL
LED Light Engine: Compact light source delivers uniform illumination without pixilation, enabling excellent beam control
ELECTRICAL
LED Light Engine: Compact light source delivers uniform illumination without pixilation, enabling excellent beam control
- 2SDCM (5000K within 3SDCM)
- 80, 90 & 97 CRI
- Replaceable light engine with push in wire connections
Passive Cooling: Aluminum heat sink integrated directly with housing provides superior thermal management to ensure the long life of LED
LED Driver:
Emergency Battery Pack (Optional) output:
LED Driver:
- Power factor >0.9
- Easily replaceable from above or below the ceiling
- Dimmable via 0-10V protocol standard
- Optional drivers available for use with eldoLED, Lutron EcoSystem, 2-wire dimmers, DMX, or DALI
- For a list of compatible dimmers, see LED-DIM
Emergency Battery Pack (Optional) output:
- Provides a minimum of 600 (BR & BRT20C), or 1000 (HBR) lumens for a minimum duration of 90 minutes
- BRT20C option is BRT20C option is CEC Title 20 compliant
