Juno L4 23LM 30K 277 G4 80CRI EZ1 Indy 4" Round New Construction Housing, 2300 Lumens, 3000K Color Temperature, 277 Volt, Generation 4, 80 CRI, eldoLED 0-10V ECO Driver

ENVIRONMENTALLY FRIENDLY, ENERGY EFFICIENT

• Lumen packages suitable for ceiling heights ranging from 8' to in excess of 100'
• Efficacies up to 128 lm/w
• Superior-quality white LED light output using Chip on Board technology
• No harmful ultraviolet or infrared wavelengths
• No lead or mercury

PRODUCT SPECIFICATIONS
Enabled with Atrius: These products are enabled with Atrius, making them part of theAtri us Sensory Network and ready to deliver valuable data and connectivity to the AtriusPlatform.

OPTICS
Hyperbolic

• Unique hyperbolic shape optimized for small, directional LED source, maximizes fixture efficiency while creating the "Silent Ceiling" appearance by reducing lamp image and aperture brightness
• Geometry of hyperbolic curve provides unique aperture appearance and smoother light distribution
• Narrow Flood, medium flood and wide flood distributions available

Wall Wash Available in Hyperbolic and Parabolic. Both providing uniform distributions with no striations
Baffle White or black painted deep multi-groove aluminum baffle insert with integral white painted flange and frosted convexed glass lens

LED Light Engine

• Compact light source delivers uniform illumination without pixilation, enabling excellent beam control
• 2SDCM (5000K within 3SDCM)
• 80, 90 & 97 CRI
• Replaceable light engine with push in wire connections

Passive Cooling Aluminum heat sink integrated directly with housing provides superior thermal management to ensure the long life of LED
LED Driver

• Power factor >0.9
• Easily replaceable from above or below the ceiling

Dimming

• Dimmable via 0-10V protocol standard
• Optional drivers available for use with eldoLED, Lutron EcoSystem, 2-wire dimmers, DMX, or DALI
• For a list of compatible dimmers, see LED-DIM.

Life

• Rated for 60,000 hours at 70% lumen maintenance
• Available with optional Lumen Depreciation Indicator (LDI)

Emergency Battery Pack (Optional) output

• Provides a minimum of 600 (BR), or 1100 (HBR) lumens for a minimum duration of 90 minutes.
• BRT20C option is CEC Title 20 compliant
