Juno Recessed Lighting J6RLWDG4N-3K-6-WWH 6" IC WarmDim LED Retrofit Downlight Trim Module 600 Lumens, 3000K Color Temperature, White Baffle, White Trim, Less Medium Base Socket Adapter
Juno Recessed Lighting J6RLWDG4N-3K-6-WWH 6" IC WarmDim LED Retrofit Downlight Trim Module 600 Lumens, 3000K Color Temperature, White Baffle, White Trim, Less Medium Base Socket Adapter
Regular price
Price:
$138.26
Regular price
Price:
Sale price
$138.26
Unit price
per
MODEL: Juno-J6RLWDG4N-3K-6-WWH
Usually Ships in 3-5 business days. Urgent Project? Contact Us
Couldn't load pickup availability
Ordering a large quantity?Request a quote
When ordering this fixture, you will get the newest generation. Different generations cannot be mixed.
description
PRODUCT DESCRIPTION
Compatible Housing
ORDERING INFORMATION
- All-in-one 6” LED Retrofit downlight trim with patented WarmDim technology installs into existing 6” incandescent housings with medium base sockets or Juno IC23-LEDT24 and IC23R-LEDT24 quick connect recessed housings
- LED color temperature warms while dimming to emulate the dimming performance of traditional incandescent light sources
- May be used in housings completely covered with insulation
- Selection of interchangeable baffle and cone trim inserts can be changed in the field to customize the look of the product
- Dimmable with most standard incandescent or electronic low voltage dimmers
- Designed to provide 50,000 hours of life
- 5 year limited warranty on LED components.
Compatible Housing
- Directly compatible IC23-LEDT24 and IC23R-LEDT24
- Also compatible with most 6” recessed housings measuring at least 5-1/4” high with an inside diameter between 6” and 6-3/4”.
- Removal of the housing socket plate or socket mounting bracket may be required in order for the trim to fit properly. If housing does not have torsion spring brackets, the V6RL-TRB accessory is required.
- Juno housings: IC2 and TC2 Series, IC22 Series, IC23 Series, IC21 Series
- Aluminum eyeball trim with white finish
- All-in-one design where LED light engine mounts directly to trim
- Up to 30˚ vertical adjustment
- Provided with torsion springs as standard
- Accessory kit available for use in housings that do not have torsion spring retaining brackets.
- LED array integrated to one piece high purity aluminum, thermally conductive eyeball housing provides uninterrupted heat transfer to ensure long life of the LED
- Replaceable light engine mounts directly to eyeball housing and incorporates the latest generation, high lumen output LED array
- LEDs are binned to standards that exceed ENERGY STAR requirements yielding superior fixture to fixture color uniformity
- 90 CRI typical.
- Dedicated 120 volt driver
- Power factor > 0.9 at 120V input
- Dimmable with the use of most incandescent, magnetic low voltage and electronic low voltage wall box dimmers
- For a list of compatible dimmers, click here.
- Computer-optimized reflector design with high reflectance white finish coupled with a high transmission diffusing lens conceals the LEDs
- Efficient system that can produce over 900 lumens while using less than 16W (Nominal input wattage under stable operating conditions.)
- Wide flood distribution shipped as standard with optional optic accessories available and sold separately.
- Trim features quick connect plug installed as standard for installation into IC23-LEDT24 and IC23R-LEDT24 housings with mating connector
- a medium base socket adapter whip sold separately.
- Rated for 50,000 hours at 70% lumen maintenance.
- ENERGY STAR Qualified to luminaires V1.1 requirements
- Suitable for damp locations
- Union made
- UL and cUL classified for use with 6” incandescent medium base housings and Juno IC23-LEDT24 or IC23R-LEDT24.
- All reports are based on published industry procedures; field performance may differ from laboratory performance.
ORDERING INFORMATION
