Juno Track Lighting T1040H-WH (T1040 H WH) Trac Master Low Voltage Horizontal Lily16 MR16 LED-Compatible Lampholders, White Finish

Juno Track Lighting T1040H-WH (T1040 H WH) Trac Master Low Voltage Horizontal Lily16 MR16 LED-Compatible Lampholders, White Finish

Price: $96.12
Price: $96.12

MODEL: Juno-T1040H-WH

Usually Ships in 3-5 business days. Urgent Project? contact us >>
Add To Wishlist
Request a Quote
Ordering a large quantity? Request a quote
View full details

description

PRODUCT DESCRIPTION
  • These low voltage fixtures offer both mechanical and electrical compatibility with most MR16 LED lamps (by others). Constructed with open or semi-open designs, this series provides for improved airflow around the lamp, leading to better cooling and optimized LED lamp life. They may also be used with MR16 halogen lamps with integral cover glass. Versions are available with either a horizontal or vertical transformer housing. The horizontal version has an integral transformer housing which is centered above the lamp holder, offering a new and unique aesthetic in a small, close-to-the-trac fixture footprint. The vertical version minimizes the fixture footprint and displaces the lamp holder away from the trac, making it ideal for installation in ceiling channels.
PRODUCT SPECIFICATIONS
Construction
  • Lamp holders are constructed of die cast aluminum
  • Transformer housings are constructed of molded poly carbonate (horizontal) or extruded aluminum (vertical).
Socket
  • GU5.3/GX5.3 ceramic bi-pin.
Lamp
  • Compatible with most 12VAC MR16 LED lamps (by others)
  • Also compatible with 50W max. 12VAC MR16 halogen lamps with integral cover glass.
Transformer
  • Hatch RS-12-60M-LED 60VA 12VAC solid state electronic
  • Integral to fixture in either horizontal or vertical orientation
  • ANSI/IEEE C62.41.Class A transient protection
  • Short circuit protection
  • Dimmable (with dimmable lamps)
Adapter
  • Copper alloy contacts provide precise spring action - no arcing and will not take a set
  • True, positive electrical ground
  • On/off switch included
  • Patented embossed polarity arrows on bottom of adapter
  • Spring-loaded positive latch with embossed polarity arrows secures trac light to trac
  • “Pull-up” contact to up position for two-circuit application.
Aiming
  • 90° vertical aiming capability and 358° rotation.
Labels
  • UL and C-UL Listed
  • Fixtures can be assembled with reduced maximum wattage rating labels to facilitate energy code compliance
Product specifications subject to change without notice.

downloads

PDF Download Download PDF Brochure
