Kim Lighting EL170DB 120 Volt Die-Cast Aluminum, Landscape Path Light, 20W-50W MR16 Halogen, Ravenna Highlighter Style, Dark Bronze Finish

PRODUCT SPECIFICATIONS

Lamp Housing: Die-cast aluminum with die-cast cover, stainless steel fasteners. Stainless steel set screw lock for aiming pivot.

Aiming: Aimable 358° vertically, horizontal aiming controlled by installation on mounting device.

Ravenna Yoke: Cast aluminum, stainless steel fasteners and K" NPSM brass nipple mount.

Lens: Tempered glass, B" nominal thickness.

Gasketing: Silicone gaskets used throughout.

Socket: G4 to GY6.35 socket for bipin lamp.

Transformer: 120 volt to 12 volt, 20 to 50 watt electronic stepdown transformer, enclosed and gasketed in yoke base.

Wiring: No. 18AWM rated 105°C.

Finish: Super TGIC thermoset polyester powder coat paint, 2.5 mil nominal thickness, applied over a titanated zirconium conversion coating; 2500 hour salt spray test endurance rating. Standard colors are Black (BL), Dark Bronze (DB), and Verde Green (GR).

Certification: UL Listed to U.S. and Canadian safety standards for wet locations.
