Kim Lighting VRB1/20L4KUV/BLT 25W LED Round Bollard, Single Function, Aluminum Shaft, Domed Top, 20 LEDs, 4000K, 120-277V, Black Matte Textured
Kim Lighting VRB1/20L4KUV/BLT 25W LED Round Bollard, Single Function, Aluminum Shaft, Domed Top, 20 LEDs, 4000K, 120-277V, Black Matte Textured
Regular price
Price:
$1,938.00
Regular price
Price:
Sale price
$1,938.00
Unit price
per
MODEL: Kim-VRB1-20L4KUV-BLT
Usually Ships in 4-6 business days. Urgent Project? Contact Us
Couldn't load pickup availability
Ordering a large quantity?Request a quote
description
PRODUCT SPECIFICATIONS
Domed Top Cap: One-piece die-cast aluminum secured to louvers by concealed allen screws in keyhole slots. For relamping access, allen screws shall not require complete removal.
Louvers: Aluminum die-cast with vertical support ribs at 90 degrees intervals. Horizontal louver blades shall have a 13/4" depth, a 65 degrees upward pitch and provide light source cutoff above horizontal. Louver assembly shall be secured to shaft by four internal tie rods.
Lamp Enclosure: One-piece tempered molded glass with internal flutes and full gasketing at bottom edge.
Fixture Head: Allows flow-through ventilation around and above the lamp enclosure.
Shaft: One-piece extruded aluminum, .125" wall thickness with a heavy cast aluminum twist-lock anchor base concealed within the shaft. Concealed set screws shall lock shaft onto the cast anchor base.
Electronic Module: All electrical components are either UL or ETL recognized, mounted on a single plate and factory prewired with quick disconnect plugs. Driver is rated for -40°F starting and has a 0-10V dimming interface for multi-level illumination options.
Optical Module: Each LED equipped with a directional optic for maximum beam angle projecting through louver stack spacings. LED boards to be mounted to an anodized inter-locking heat sink extrusion. (Type I) two 5-LED boards for a total of 10-LED. (Type III) three 5-LED boards for a total of 15-LED. (Type V) four 5-LED boards for a total of 20-LED. Available in 580nm Amber, 3000K, 4000K and 5000K color temperatures.
Anchor Bolts: Four 3/8" x 10" + 2" zinc plated L-hooks, each with two nuts, washers and a rigid pressed board template.
Finish: Each luminaire receives a fade and abrasion resistant, electrostatically applied, thermally cured, triglycidal isocyanurate (TGIC) polyester powdercoat finish.
Listed to: UL 1598 Standard for Luminaires - UL 8750 Standard for Safety for Light Emitting Diode (LED) Equipment for use in Lighting Products and CSA C22.2#250.0 Luminaires. RoHS compliant. Meets Buy American provisions within ARRA.
Domed Top Cap: One-piece die-cast aluminum secured to louvers by concealed allen screws in keyhole slots. For relamping access, allen screws shall not require complete removal.
Louvers: Aluminum die-cast with vertical support ribs at 90 degrees intervals. Horizontal louver blades shall have a 13/4" depth, a 65 degrees upward pitch and provide light source cutoff above horizontal. Louver assembly shall be secured to shaft by four internal tie rods.
Lamp Enclosure: One-piece tempered molded glass with internal flutes and full gasketing at bottom edge.
Fixture Head: Allows flow-through ventilation around and above the lamp enclosure.
Shaft: One-piece extruded aluminum, .125" wall thickness with a heavy cast aluminum twist-lock anchor base concealed within the shaft. Concealed set screws shall lock shaft onto the cast anchor base.
Electronic Module: All electrical components are either UL or ETL recognized, mounted on a single plate and factory prewired with quick disconnect plugs. Driver is rated for -40°F starting and has a 0-10V dimming interface for multi-level illumination options.
Optical Module: Each LED equipped with a directional optic for maximum beam angle projecting through louver stack spacings. LED boards to be mounted to an anodized inter-locking heat sink extrusion. (Type I) two 5-LED boards for a total of 10-LED. (Type III) three 5-LED boards for a total of 15-LED. (Type V) four 5-LED boards for a total of 20-LED. Available in 580nm Amber, 3000K, 4000K and 5000K color temperatures.
Anchor Bolts: Four 3/8" x 10" + 2" zinc plated L-hooks, each with two nuts, washers and a rigid pressed board template.
Finish: Each luminaire receives a fade and abrasion resistant, electrostatically applied, thermally cured, triglycidal isocyanurate (TGIC) polyester powdercoat finish.
Listed to: UL 1598 Standard for Luminaires - UL 8750 Standard for Safety for Light Emitting Diode (LED) Equipment for use in Lighting Products and CSA C22.2#250.0 Luminaires. RoHS compliant. Meets Buy American provisions within ARRA.
Download PDF Specification Share your knowledge of this product. Be the first to write a review »
