Lithonia 2GTL4 LP835 2x4 LED Recessed Troffer 4104 Lumens 39 Watt 3500K
Lithonia 2GTL4 LP835 2x4 LED Recessed Troffer 4104 Lumens 39 Watt 3500K
Regular price
Price:
$192.15
Regular price
Price:
Sale price
$192.15
Unit price
per
MODEL: Lithonia-2GTL-2X4-105179
Usually Ships in 3-5 business days. Urgent Project? Contact Us
Couldn't load pickup availability
Ordering a large quantity?Request a quote
description
INTENDED USE -- The 2GTL LED recessed troffer offers a wide range of lumen packages, color temperatures, and lens options to meet the lighting needs for a wide range of applications such as schools, offices, and hospitals. The light engine delivers long life and excellent color to ensure a sound quality, low-maintenance lighting installation. Certain airborne contaminants can diminish the integrity of acrylic and/ or polycarbonate. Click here for Acrylic Environmental Compatibility table for suitable uses.
CONSTRUCTION -- Housing formed from 22 gauge cold-rolled steel. Smooth hemmed sides and smooth inward formed end flanges for safe handling. Includes integral T-bar clips. Lighter-weight fixture allows for safe, easy installation.
OPTICS -- Highly transmissive pattern #12 lens diffuses the light source without compromising output.
Pattern # 19 and satin white lens options also available.
ELECTRICAL -- Long-life LEDs, coupled with high-efficiency drivers, provide extended service life. 80% LED lumen maintenance at 72,000 hours (L80/72,000).
eldoLED driver options deliver choice of dimming range, and choices for control, while assuring flicker-free, low-current inrush, 89% efficiency and low EMI.
Optional nLight embedded controls make each luminaire addressable - allowing it to digitally communicate with other nLight enabled controls such as dimmers, switches, occupancy sensors and photocontrols. Simply connect all the nLight enabled control devices and the GTL luminaires using standard Cat-5 cabling. Unique plug-and-play convenience as devices and luminaires automatically discover each other and self-commission.
Lumen Management: Unique lumen management system (option N80) provides onboard intelligence that actively manages the LED light source so that constant lumen output is maintained over the system life, preventing the energy waste created by the traditional practice of over-lighting.
The step-level dimming option (SLD) allows the system to be switched to 50% power for compliance with common energy codes while maintaining fixture appearance.
Ballast disconnect is provided where required to comply with U.S. and Canadian codes.
INSTALLATION -- LED boards include plug-in connectors for easy of upgradeability. Suitable for direct insulation contact. Suitable for damp location.
LISTINGS -- CSA certified to meet U.S. and Canadian standards. IC rated. DesignLights Consortium (DLC)
Premium qualified product. Not all versions of this product may be DLC Premium qualified. Please check the DLC Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified.
WARRANTY -- 5-year limited warranty.
CONSTRUCTION -- Housing formed from 22 gauge cold-rolled steel. Smooth hemmed sides and smooth inward formed end flanges for safe handling. Includes integral T-bar clips. Lighter-weight fixture allows for safe, easy installation.
OPTICS -- Highly transmissive pattern #12 lens diffuses the light source without compromising output.
Pattern # 19 and satin white lens options also available.
ELECTRICAL -- Long-life LEDs, coupled with high-efficiency drivers, provide extended service life. 80% LED lumen maintenance at 72,000 hours (L80/72,000).
eldoLED driver options deliver choice of dimming range, and choices for control, while assuring flicker-free, low-current inrush, 89% efficiency and low EMI.
Optional nLight embedded controls make each luminaire addressable - allowing it to digitally communicate with other nLight enabled controls such as dimmers, switches, occupancy sensors and photocontrols. Simply connect all the nLight enabled control devices and the GTL luminaires using standard Cat-5 cabling. Unique plug-and-play convenience as devices and luminaires automatically discover each other and self-commission.
Lumen Management: Unique lumen management system (option N80) provides onboard intelligence that actively manages the LED light source so that constant lumen output is maintained over the system life, preventing the energy waste created by the traditional practice of over-lighting.
The step-level dimming option (SLD) allows the system to be switched to 50% power for compliance with common energy codes while maintaining fixture appearance.
Ballast disconnect is provided where required to comply with U.S. and Canadian codes.
INSTALLATION -- LED boards include plug-in connectors for easy of upgradeability. Suitable for direct insulation contact. Suitable for damp location.
LISTINGS -- CSA certified to meet U.S. and Canadian standards. IC rated. DesignLights Consortium (DLC)
Premium qualified product. Not all versions of this product may be DLC Premium qualified. Please check the DLC Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified.
WARRANTY -- 5-year limited warranty.
Download PDF SpecificationShare your knowledge of this product. Be the first to write a review »
