Lithonia ASW1 LED 42C 700 40K SR3 347 BBW DWHGXD 98W Aeris Outdoor LED Wallpack, 42 LEDs (One Engine), 700mA, 4000K, Type III Distribution, 347V, Surface-Mounted Back Box, Textured White Finish

Intended Use

For building- and wall-mounted applications.

Construction

Rugged, die-cast, single-piece aluminum housing. Die-cast doorframe has impact-resistant, tempered, glass lens. Doorframe is fully sealed with a closed-cell silicone gasket.

Finish: Exterior parts are protected by a zinc-infused Super Durable TGIC thermoset powder coat finish that provides superior resistance to corrosion and weathering. A tightly controlled multi-stage process ensures a minimum 3 mm thickness for a finish that can withstand extreme climate changes without cracking or peeling. Standard Super Durable colors include dark bronze, black, natural aluminum and white. Available in textured and non-textured finishes.

Optics

Precision acrylic refractive optics for optimum light distribution through the flat glass lens. Available with Type 2, Type 3 and Type 4.

Electrical

High-efficiency nominal 4000K, 65 CRI LEDs mounted to a metal-core circuit board and aluminum heat sink, ensuring optimal thermal management and long life. Designed to provide more than 60,000 hours of performance (L85) at 250C (770F) ambient temperatures. Standard and dimming drivers are available in 120-277V and 347-480V; 50/60 Hz. Drivers have power factor >90% and THD <20%. Expected driver life is over 60,000 hours, matching the light engine life. Integral surge protection tested in accordance with IEEE/ANSI C62.41.2 to Category C Low.

Installation

Universal mounting plate with integral mounting bolts supports the fixture for easy, one-person installation.

Listings

CSA Certified to U.S. and Canadian standards. Down orientation only. IP65 rated. US. Patent No. D500,569. Canada Patent No. 107561.

WARRANTY: Five-year limited warranty.
