Lithonia CPHB ALO16 MVOLT SWW9 80CRI DWH Compact Pro LED High Bay, 24000/27000/30000 Lumens, 120-277V, 0-10V Dimming Driver, 4000K/5000K Color Temperature 80 CRI, White
Lithonia CPHB ALO16 MVOLT SWW9 80CRI DWH Compact Pro LED High Bay, 24000/27000/30000 Lumens, 120-277V, 0-10V Dimming Driver, 4000K/5000K Color Temperature 80 CRI, White
Regular price
Price:
$216.56
Regular price
Price:
Sale price
$216.56
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
INTENDED USE
INTENDED USE
Ideal one-for-one replacement of conventional lighting systems such as HID and fluorescent. For use in light Industrial applications such as warehousing and other large indoor
spaces with mounting heights ranging from 10' – permitted. Certain airborne contaminants can diminish integrity of acrylic and/or polycarbonate.
Click here for Acrylic-Polycarbonate Compatibility table for suitable uses.
Certain airborne contaminants, including condensation, may adversely affect the functioning of LEDs and other electronic components, depending on various factors such as concentrations of the contaminants, ventilation, and temperature at the end-user location.
Click here for a list of substances that may not be suitable for interaction with LEDs and other electronic components.
CONSTRUCTION
Extruded aluminum channels enable superior thermal performance.
Glare Control Lens diffuses light source and reduces glare while protecting LEDs.
Lens meets DLC 5.1 standards for UGR (Unified Glare Rating)
Available in three sizes with optional switchable lumens (12000/15000/18000 or 24000/27000/30000 or 36000/48000/60000) and color temperatures (4000K/5000K
ELECTRICAL
70% lumen maintenance at > 100,000 hours.
Thermally protected driver standard with 0-10V dimming.
Luminaire surge protection level: designed to withstand up to 6kV/3kA per ANSI C82.77‑5‑2015.
Multi-volt driver, 120-277V standard. UVOLT driver, 120-347V with switchable versions.
6ft cord included with ALO13 and ALO16 UVOLT fixtures.
INSTALLATION
Fixture package includes V-hanger hardware kit with 2- V-hanger brackets and 2- 36" chain lengths.
Fixture is suitable for mounting by chain, cable, surface-mount bracket, or hook monopoint.
Surface mounting available using optional THUN surface mount bracket (order separately).
Designed for use in ambient temperatures ranging from -40°C to 55°C when suspended 18" off ceiling. Max operating temperature of 45°C when surface mounted.
Note: Temperature cycling, or variations can potentially produce condensation; please consult factory.
LISTINGS
CSA listed. Damp location listed.
DesignLights Consortium® (DLC) Premium qualified product. Not all versions of this product may be DLC Premium qualified. Please check the DLC Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified.
UVOLT Fixtures not NOM Certified.
WARRANTY
5-year limited warranty.
Click here for Acrylic-Polycarbonate Compatibility table for suitable uses.
Certain airborne contaminants, including condensation, may adversely affect the functioning of LEDs and other electronic components, depending on various factors such as concentrations of the contaminants, ventilation, and temperature at the end-user location.
Click here for a list of substances that may not be suitable for interaction with LEDs and other electronic components.
CONSTRUCTION
Extruded aluminum channels enable superior thermal performance.
Glare Control Lens diffuses light source and reduces glare while protecting LEDs.
Lens meets DLC 5.1 standards for UGR (Unified Glare Rating)
Available in three sizes with optional switchable lumens (12000/15000/18000 or 24000/27000/30000 or 36000/48000/60000) and color temperatures (4000K/5000K
ELECTRICAL
70% lumen maintenance at > 100,000 hours.
Thermally protected driver standard with 0-10V dimming.
Luminaire surge protection level: designed to withstand up to 6kV/3kA per ANSI C82.77‑5‑2015.
Multi-volt driver, 120-277V standard. UVOLT driver, 120-347V with switchable versions.
6ft cord included with ALO13 and ALO16 UVOLT fixtures.
INSTALLATION
Fixture package includes V-hanger hardware kit with 2- V-hanger brackets and 2- 36" chain lengths.
Fixture is suitable for mounting by chain, cable, surface-mount bracket, or hook monopoint.
Surface mounting available using optional THUN surface mount bracket (order separately).
Designed for use in ambient temperatures ranging from -40°C to 55°C when suspended 18" off ceiling. Max operating temperature of 45°C when surface mounted.
Note: Temperature cycling, or variations can potentially produce condensation; please consult factory.
LISTINGS
CSA listed. Damp location listed.
DesignLights Consortium® (DLC) Premium qualified product. Not all versions of this product may be DLC Premium qualified. Please check the DLC Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified.
UVOLT Fixtures not NOM Certified.
WARRANTY
5-year limited warranty.
