Lithonia LO3BR TRIM 3 Inch Round Downlight Black Reflector Trim
Lithonia LO3BR TRIM 3 Inch Round Downlight Black Reflector Trim
Regular price
Price:
$74.14
Regular price
Price:
Sale price
$74.14
Unit price
per
MODEL: Lithonia-LDN3-106840
Usually Ships in 3-5 business days. Urgent Project?
contact us >>
Couldn't load pickup availability
Ordering a large quantity?
Request a quote
description
TRIM -- Trim is sold separately. Please click here for compatible trims.
INTENDED USE -- Typical applications include corridors, lobbies, conference rooms and private offices.
CONSTRUCTION -- Install from below construction standard.
Additional mounting options available including new construction mounting pan and Chicago plenum.
Ambient operating temperature: 25 degree C. High ambient option available.
Light engine and driver are accessible from above or below ceiling.
Passive cooling thermal management
Max ceiling thickness 1-1/4"
OPTICS -- 3 SDCM; 80 CRI typical
Diffusing lens covers optical chamber
55 degree cutoff to source and source image
Self-flanged anodized reflectors in specular, semi-specular, or matte diffuse finishes.
ELECTRICAL -- 120V TRIAC or ELV dimming and Multi-volt 0-10V dimming available.
0-10V dimming fixture requires two (2) additional low-voltage wires to be pulled
70% lumen maintenance at 50,000 hours
LISTINGS -- Certified to US and Canadian safety standards. Damp location standard (wet location, covered ceiling optional).
WARRANTY -- 5-year limited warranty.
INTENDED USE -- Typical applications include corridors, lobbies, conference rooms and private offices.
CONSTRUCTION -- Install from below construction standard.
Additional mounting options available including new construction mounting pan and Chicago plenum.
Ambient operating temperature: 25 degree C. High ambient option available.
Light engine and driver are accessible from above or below ceiling.
Passive cooling thermal management
Max ceiling thickness 1-1/4"
OPTICS -- 3 SDCM; 80 CRI typical
Diffusing lens covers optical chamber
55 degree cutoff to source and source image
Self-flanged anodized reflectors in specular, semi-specular, or matte diffuse finishes.
ELECTRICAL -- 120V TRIAC or ELV dimming and Multi-volt 0-10V dimming available.
0-10V dimming fixture requires two (2) additional low-voltage wires to be pulled
70% lumen maintenance at 50,000 hours
LISTINGS -- Certified to US and Canadian safety standards. Damp location standard (wet location, covered ceiling optional).
WARRANTY -- 5-year limited warranty.
Download PDF SpecificationShare your knowledge of this product. Be the first to write a review »
