Lithonia RB4A SWW5 MW 4" Adjustable LED Trim Kit, Switchable Color Temperature 2700K, 3000K, 3500K, 4000K, 5000K, Matte White

Lithonia RB4A SWW5 MW 4" Adjustable LED Trim Kit, Switchable Color Temperature 2700K, 3000K, 3500K, 4000K, 5000K, Matte White

Price: $27.26
Price: $27.26

MODEL: Lithonia-RB4A-SWW5-110424

Usually Ships in 3-5 business days. Urgent Project? contact us >>
Add To Wishlist
Request a Quote
Ordering a large quantity? Request a quote
View full details

description

PRODUCT SPECIFICATIONS
ADJUSTABLE LED TRIM KIT:
  • Cast aluminum trim flange in matte white with hybrid aluminum plastic housing
  • Up to 35° vertical adjustment
  • Friction springs allows for horizontal placement anywhere within the round housing
  • Pressed-in diffusing lens optimized for concealing the LEDs from direct view in the on and off state
  • All-in-one design where LED light engine mounts directly to the trim for ease of installation into existing 4" recessed housings with medium base sockets or quick connect LED housings
  • Provided with push-in friction springs
LED LIGHT ENGINE:
  • LEDs are mounted directly to housing providing superior thermal management to ensure long life
  • Switchable white LED color temperature technology offers 2700K, 3000K, 3500K, 4000K, 5000K all in one trim • Switch factory set at 3000K • 90 CRI minimum
  • Accommodates 120 volts AC at 60Hz
  • Dimmable with most standard incandescent, magnetic low voltage and electronic low voltage dimmers • For a list of compatible dimmers, see JUNORBSERIES-DIM
OPTICAL SYSTEM:
  • Regressed, diffused lens at end of mixing chamber to provide even light distribution for accent lighting
  • Nominal 700L is equivalent to 65W BR30 lamp
ELECTRICAL CONNECTIONS:
  • Trim features quick connect plug installed as standard for installation into Juno quick connect housings with mating connector
  • Trim ships with a medium base socket adapter whip for installation into 4" incandescent housings with medium base sockets.
LIFE:
  • Rated for 50,000 hours at 70% lumen maintenance.
LABELS:
  • ETL certified to US and Canadian safety standards
  • ENERGY STAR certified product
  • Suitable for damp location
  • NOM Certified
  • Can be used to comply with California Title 24 Part 6 High Efficacy LED light Source Requirements
  • T20 Certified.
WARRANTY:
  • 5-year limited warranty.
