Home > Lithonia Lighting > Lithonia REBL ALO13 UVOLT SWW3 80CRI DBL M2 LED Round High Bay, Switchable Lumens 12000LM/15000LM/18000LM, 120-347V, UVOLT Driver, Switchable CCT 3500K/4000K/5000K, 80 CRI, Matte Black
Lithonia REBL ALO13 UVOLT SWW3 80CRI DBL M2 LED Round High Bay, Switchable Lumens 12000LM/15000LM/18000LM, 120-347V, UVOLT Driver, Switchable CCT 3500K/4000K/5000K, 80 CRI, Matte Black
Lithonia REBL ALO13 UVOLT SWW3 80CRI DBL M2 LED Round High Bay, Switchable Lumens 12000LM/15000LM/18000LM, 120-347V, UVOLT Driver, Switchable CCT 3500K/4000K/5000K, 80 CRI, Matte Black
Regular price
Price:
$183.36
Regular price
Price:
Sale price
$183.36
Unit price
per
Ordering a large quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
INTENDED USE -- Ideal one-for-one replacement of traditional HID and fluorescent lighting. For use in Industrial applications including warehousing, retail spaces, and manufacturing environments with mounting heights ranging from 10' +. Certain airborne contaminants can diminish integrity of acrylic and LED's. Click here for Polycarbonate Environmental Compatibility table for suitable uses.
INTENDED USE -- Ideal one-for-one replacement of traditional HID and fluorescent lighting. For use in Industrial applications including warehousing, retail spaces, and manufacturing environments with mounting heights ranging from 10' +. Certain airborne contaminants can diminish integrity of acrylic and LED's. Click here for Polycarbonate Environmental Compatibility table for suitable uses.
Certain airborne contaminants may adversely affect the functioning of LEDs and other electronic components, depending on various factors such as concentrations of the contaminants, ventilation, and temperature at the end-user location. Click here for a list of substances that may not be suitable for interaction with LEDs and other electronic components.
CONSTRUCTION -- REBL features patent pending micro-prism optics that deliver uniform and comfortable illumination across the entire space. The rugged diecast aluminum housing and the polycarbonate lens are IK10 impact rated, providing protection from flying objects without the need for a wireguard. Available in four switchable lumen package options and two color temperature options (3500K/4000K/5000K up to 30,000 lumens, 4000K/5000K for 30,000 to 55,000 lumens).
FINISH -- Black and white finishes available.
ELECTRICAL -- High-efficiency LEDs provide up to 187 LPW. Thermally protected driver standard with 0-10V continuous dimming allowing for 10% to 100% dimming capability. Fixture comes with standard 6’ power cord and 6’ low voltage dimming cords. Projected lumen maintenance L70 > 100,000 hours. Luminaire surge protection level: designed to withstand up to 6kV/3kA per ANSI C82.77-5-2015.
INSTALLATION -- Fixture includes patented flip hook with safety latch. The hook can be flipped down and mounted with the ¾ inch threaded pendant mount. Optional cast loop or surface mount bracket available.
LISTINGS --UL/C-UL listed to US and Canadian safety standards. Wet location listed. IP66, NEMA 4X, and NSF Splash Zone 2 rated. Designed for use in ambient temperatures ranging from -40°C to 55°C when suspended 18" from ceiling.
DesignLights Consortium (DLC) Premium qualified product. Not all versions of this product may be DLC Premium qualified. Please check the DLC Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified.
WARRANTY -- 5-year limited warranty.
CONSTRUCTION -- REBL features patent pending micro-prism optics that deliver uniform and comfortable illumination across the entire space. The rugged diecast aluminum housing and the polycarbonate lens are IK10 impact rated, providing protection from flying objects without the need for a wireguard. Available in four switchable lumen package options and two color temperature options (3500K/4000K/5000K up to 30,000 lumens, 4000K/5000K for 30,000 to 55,000 lumens).
FINISH -- Black and white finishes available.
ELECTRICAL -- High-efficiency LEDs provide up to 187 LPW. Thermally protected driver standard with 0-10V continuous dimming allowing for 10% to 100% dimming capability. Fixture comes with standard 6’ power cord and 6’ low voltage dimming cords. Projected lumen maintenance L70 > 100,000 hours. Luminaire surge protection level: designed to withstand up to 6kV/3kA per ANSI C82.77-5-2015.
INSTALLATION -- Fixture includes patented flip hook with safety latch. The hook can be flipped down and mounted with the ¾ inch threaded pendant mount. Optional cast loop or surface mount bracket available.
LISTINGS --UL/C-UL listed to US and Canadian safety standards. Wet location listed. IP66, NEMA 4X, and NSF Splash Zone 2 rated. Designed for use in ambient temperatures ranging from -40°C to 55°C when suspended 18" from ceiling.
DesignLights Consortium (DLC) Premium qualified product. Not all versions of this product may be DLC Premium qualified. Please check the DLC Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified.
WARRANTY -- 5-year limited warranty.
Download PDF SpecificationShare your knowledge of this product. Be the first to write a review »
