Home > Lithonia Lighting > Lithonia SPX 2X2 3400LM 90CRI 30K BFR 3DCB MIN10 ZT MVOLT MW 2'x2' LED Troffer, 3400 Lumens, 90 CRI, 3000K, Bezel Frame, 3D Center Basket, Dims to 10%, Generic 0-10V Dimming, 120-277V, Matte White
Lithonia SPX 2X2 3400LM 90CRI 30K BFR 3DCB MIN10 ZT MVOLT MW 2'x2' LED Troffer, 3400 Lumens, 90 CRI, 3000K, Bezel Frame, 3D Center Basket, Dims to 10%, Generic 0-10V Dimming, 120-277V, Matte White
Lithonia SPX 2X2 3400LM 90CRI 30K BFR 3DCB MIN10 ZT MVOLT MW 2'x2' LED Troffer, 3400 Lumens, 90 CRI, 3000K, Bezel Frame, 3D Center Basket, Dims to 10%, Generic 0-10V Dimming, 120-277V, Matte White
Regular price
Price:
$346.25
Regular price
Price:
Sale price
$346.25
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
INTENDED USE
SPX fully-luminous lay-in luminaire with multiple optics options is designed to meet the personality of any space. Providing a visually interesting, low glare solution SPX provides performance, configurability, value and style. A typically configured SPX features a Unified Glare Rating (UGR) starting at 14. North American manufacturing allows for short lead-times. Certain airborne contaminants can diminish the integrity of acrylic and/or polycarbonate. Click here for Acrylic-Polycarbonate Compatibility table for suitable uses.
CONSTRUCTION
Built on a direct lit platform the SPX luminaire was designed for durability, depth and elegance. The bezeled frame option features a 0.6" regress to provide physical depth. MicroPrismatix and NanoPrismatix low glare lens options create superior visual comfort. The 1.25MM thick optical layer includes 3D optics options (Patents Pending) that add perceived depth. SPX has a low-profile design to provide increased installation flexibility in restricted plenum spaces. The .66MM thick back-plate includes integral T-bar clips for installation into 9/16" and 15/16" T-grid ceilings with no additional components. In a 9/16" T-grid ceiling, the bezel frame option allows the bottom of the panel sits flush with tegular ceiling tiles. Antimicrobial paint finish available.
Networked embedded controls: Networked embedded controls by nLight address the requirements of Luminaire Level Lighting Controls (LLLC). Luminaires with networked embedded controls by nLight are designed, manufactured, tested, and shipped with occupancy, daylight sensors or control devices factory-installed. This simplifies design layouts and reduces total installed cost by eliminates field installation of control devices, while addressing code requirements.
Standalone embedded controls: Luminaires with standalone embedded controls by Sensorswitch are designed, manufactured, tested, and shipped with the sensor or control device factory-installed. This simplifies design layouts and reduces total installed cost by eliminating field installation of control devices.
ELECTRICAL
Long-life LEDs, coupled with a high-efficiency driver, provide superior illumination for extended service life. LEDs feature a 3 step macadam ellipse binning. 0-10V dimming driver, dims to 1% or 10%. EldoLED and step level dimming drivers are available. Luminaire surge level protection designed to withstand surge up to 2.0kV. SPX offers 8 different lumen packages ranging from 2000 to 10200 lumens with.
LISTINGS
CSA certified to meet US and Canadian standards. Intended for indoor use in ambient temperatures up to 25° C. Damp location listed. IC rated. IP5X rated. Rated for NSF/ANSI Standard 2 -- Light Fixture for Splash Zone and Non Food Zone. Tested in accordance with ISO 14644-1; suitable for ISO Class 5–9 positive and negative pressure clean rooms.
DesignLights Consortium® (DLC) Premium qualified product and DLC qualified product. Not all versions of this product may be DLC Premium qualified or DLC qualified. Please check the DLC Qualified Products
List at www.designlights.org/QPL to confirm which versions are qualified.
WARRANTY
5-year limited warranty.
INTENDED USE
SPX fully-luminous lay-in luminaire with multiple optics options is designed to meet the personality of any space. Providing a visually interesting, low glare solution SPX provides performance, configurability, value and style. A typically configured SPX features a Unified Glare Rating (UGR) starting at 14. North American manufacturing allows for short lead-times. Certain airborne contaminants can diminish the integrity of acrylic and/or polycarbonate. Click here for Acrylic-Polycarbonate Compatibility table for suitable uses.
CONSTRUCTION
Built on a direct lit platform the SPX luminaire was designed for durability, depth and elegance. The bezeled frame option features a 0.6" regress to provide physical depth. MicroPrismatix and NanoPrismatix low glare lens options create superior visual comfort. The 1.25MM thick optical layer includes 3D optics options (Patents Pending) that add perceived depth. SPX has a low-profile design to provide increased installation flexibility in restricted plenum spaces. The .66MM thick back-plate includes integral T-bar clips for installation into 9/16" and 15/16" T-grid ceilings with no additional components. In a 9/16" T-grid ceiling, the bezel frame option allows the bottom of the panel sits flush with tegular ceiling tiles. Antimicrobial paint finish available.
Networked embedded controls: Networked embedded controls by nLight address the requirements of Luminaire Level Lighting Controls (LLLC). Luminaires with networked embedded controls by nLight are designed, manufactured, tested, and shipped with occupancy, daylight sensors or control devices factory-installed. This simplifies design layouts and reduces total installed cost by eliminates field installation of control devices, while addressing code requirements.
Standalone embedded controls: Luminaires with standalone embedded controls by Sensorswitch are designed, manufactured, tested, and shipped with the sensor or control device factory-installed. This simplifies design layouts and reduces total installed cost by eliminating field installation of control devices.
ELECTRICAL
Long-life LEDs, coupled with a high-efficiency driver, provide superior illumination for extended service life. LEDs feature a 3 step macadam ellipse binning. 0-10V dimming driver, dims to 1% or 10%. EldoLED and step level dimming drivers are available. Luminaire surge level protection designed to withstand surge up to 2.0kV. SPX offers 8 different lumen packages ranging from 2000 to 10200 lumens with.
LISTINGS
CSA certified to meet US and Canadian standards. Intended for indoor use in ambient temperatures up to 25° C. Damp location listed. IC rated. IP5X rated. Rated for NSF/ANSI Standard 2 -- Light Fixture for Splash Zone and Non Food Zone. Tested in accordance with ISO 14644-1; suitable for ISO Class 5–9 positive and negative pressure clean rooms.
DesignLights Consortium® (DLC) Premium qualified product and DLC qualified product. Not all versions of this product may be DLC Premium qualified or DLC qualified. Please check the DLC Qualified Products
List at www.designlights.org/QPL to confirm which versions are qualified.
WARRANTY
5-year limited warranty.
