Home > Lithonia Lighting > Lithonia WL4 30L EZ1 E10W LP850 MSD7 4' Wall Mounted LED, 3000 Lumens, eldoLED Dims to 1%, 0-10V, 80 CRI, 5000K, Sensor Switch MSD 7, 10W Emergency Battery Pack
Lithonia WL4 30L EZ1 E10W LP850 MSD7 4' Wall Mounted LED, 3000 Lumens, eldoLED Dims to 1%, 0-10V, 80 CRI, 5000K, Sensor Switch MSD 7, 10W Emergency Battery Pack
Lithonia WL4 30L EZ1 E10W LP850 MSD7 4' Wall Mounted LED, 3000 Lumens, eldoLED Dims to 1%, 0-10V, 80 CRI, 5000K, Sensor Switch MSD 7, 10W Emergency Battery Pack
Regular price
Price:
$690.36
Regular price
Price:
Sale price
$690.36
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
INTENDED USE
For wall or ceiling mounting, vertical or horizontal. The WL combines digital LED lighting and controls technologies with high-performance optical design to offer the most advanced wall-mount luminaire for general ambient lighting applications. High-efficacy light engine delivers long life and excellent color, ensuring a superior quality lighting installation that is highly efficient and sustainable.
CONSTRUCTION
Housing is roll formed from code-gauge steel.
INTENDED USE
For wall or ceiling mounting, vertical or horizontal. The WL combines digital LED lighting and controls technologies with high-performance optical design to offer the most advanced wall-mount luminaire for general ambient lighting applications. High-efficacy light engine delivers long life and excellent color, ensuring a superior quality lighting installation that is highly efficient and sustainable.
CONSTRUCTION
Housing is roll formed from code-gauge steel.
Refractor is retained in die cast ends providing secure installation and easy maintenance.
Decorative die-cast end caps provide added durability.
Finish: End caps are post-painted in white polyester powder coat for smooth finish. Post-painted channel available by selecting PAF option.
OPTICS
Impact modified linear faceted refractor. Optically engineered for superior light distribution and maximum efficacy.
Crescent-shape linear faceted refractor system obscures and integrates individual LED images and uniformly washes fixture surface with light.
ELECTRICAL
Long-life LEDs, coupled with high-efficiency drivers, provide superior quantity and quality of illumination for extended service life. 90% LED lumen maintenance at 60,000 hours (L90/60,000). The LEDs have a CRI of 82. eldoLED driver options deliver choice of dimming range and choice for control, while assuring flicker-free, low-current inrush, 89% efficiency and low EMI.
Driver disconnect provided where required to comply with US and Canadian codes.
Optional nLight embedded controls continuously monitor system performance and allow for constant lumen management function.
Lumen Management: Unique lumen management system (option N80) provides onboard intelligence that actively manages the LED light source so that constant lumen output is maintained over the system life, preventing energy waste created by the traditional practice of over-lighting.
SENSOR
Integrated sensor (individual control): Sensor Switch MSD7 (Passive Infrared (PIR)) integrated occupancy sensor photocell allows the luminaire to power off when the space is unoccupied.
See page 4 for more details on the integrated sensor.
Integrated Sensor (nLight Wired Networking): The sensor is nLight-enabled, meaning it has the ability to communicate over an nLight network. When wired using CAT-5 cabling with other nLight-enabled sensors, power packs, or WallPods, an nLight control zone is created. Once linked to a Gateway, directly or via a Bridge, the zone becomes capable of remote status monitoring and control via SensorView software. See page 4 for the nLight sensor options.
Interated Smart Sensor (nLight AIR Wireless Platform): The RES7 sensor is nLight AIR enabled, meaning it has the ability to communicate over the wireless nLight control platform. It is available with an automatic dimming photocell, and either a digital PIR or a dual technology occupancy sensor. It pairs to other luminaires and wall switches through our mobile app, CLAIRITY, which allows for simple sensor adjustment. See page 4 for more details on the Integrated Smart Sensor.
LISTINGS
CSA certified to meet U.S. and Canadian standards. Suitable for damp location.
Patents pending. DesignLights Consortium (DLC) qualified product. Not all versions of this product may be DLC qualified. Please check the DLC Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified.
GOVERNMENT PROCUREMENT
BAA -- Product with the BAA option qualifies as a domestic end product under the Buy American Act as implemented in the FAR and DFARS. Product with the BAA option also qualifies as manufactured in the United States under DOT Buy America regulations.
BABA -- Build America Buy America: Product with the BAA option also qualifies as produced in the United States under the definitions of the Build America, Buy America Act.
Please refer to www.acuitybrands.com/buy-american for additional information.
WARRANTY
5-year limited warranty.
Decorative die-cast end caps provide added durability.
Finish: End caps are post-painted in white polyester powder coat for smooth finish. Post-painted channel available by selecting PAF option.
OPTICS
Impact modified linear faceted refractor. Optically engineered for superior light distribution and maximum efficacy.
Crescent-shape linear faceted refractor system obscures and integrates individual LED images and uniformly washes fixture surface with light.
ELECTRICAL
Long-life LEDs, coupled with high-efficiency drivers, provide superior quantity and quality of illumination for extended service life. 90% LED lumen maintenance at 60,000 hours (L90/60,000). The LEDs have a CRI of 82. eldoLED driver options deliver choice of dimming range and choice for control, while assuring flicker-free, low-current inrush, 89% efficiency and low EMI.
Driver disconnect provided where required to comply with US and Canadian codes.
Optional nLight embedded controls continuously monitor system performance and allow for constant lumen management function.
Lumen Management: Unique lumen management system (option N80) provides onboard intelligence that actively manages the LED light source so that constant lumen output is maintained over the system life, preventing energy waste created by the traditional practice of over-lighting.
SENSOR
Integrated sensor (individual control): Sensor Switch MSD7 (Passive Infrared (PIR)) integrated occupancy sensor photocell allows the luminaire to power off when the space is unoccupied.
See page 4 for more details on the integrated sensor.
Integrated Sensor (nLight Wired Networking): The sensor is nLight-enabled, meaning it has the ability to communicate over an nLight network. When wired using CAT-5 cabling with other nLight-enabled sensors, power packs, or WallPods, an nLight control zone is created. Once linked to a Gateway, directly or via a Bridge, the zone becomes capable of remote status monitoring and control via SensorView software. See page 4 for the nLight sensor options.
Interated Smart Sensor (nLight AIR Wireless Platform): The RES7 sensor is nLight AIR enabled, meaning it has the ability to communicate over the wireless nLight control platform. It is available with an automatic dimming photocell, and either a digital PIR or a dual technology occupancy sensor. It pairs to other luminaires and wall switches through our mobile app, CLAIRITY, which allows for simple sensor adjustment. See page 4 for more details on the Integrated Smart Sensor.
LISTINGS
CSA certified to meet U.S. and Canadian standards. Suitable for damp location.
Patents pending. DesignLights Consortium (DLC) qualified product. Not all versions of this product may be DLC qualified. Please check the DLC Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified.
GOVERNMENT PROCUREMENT
BAA -- Product with the BAA option qualifies as a domestic end product under the Buy American Act as implemented in the FAR and DFARS. Product with the BAA option also qualifies as manufactured in the United States under DOT Buy America regulations.
BABA -- Build America Buy America: Product with the BAA option also qualifies as produced in the United States under the definitions of the Build America, Buy America Act.
Please refer to www.acuitybrands.com/buy-american for additional information.
WARRANTY
5-year limited warranty.
Download PDF SpecificationShare your knowledge of this product. Be the first to write a review »
