Lumiere 203-50MR16-12-BK 50W Cambria Landscape Light, Standard Side Swivel Stem, Halogen MR16, GU5.3 Base , 12V, Black
Lumiere 203-50MR16-12-BK 50W Cambria Landscape Light, Standard Side Swivel Stem, Halogen MR16, GU5.3 Base , 12V, Black
Regular price
Price:
$185.13
Regular price
Price:
Sale price
$185.13
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
Material
Material
- Housing, hood and mounting stem are precisionmachined from corrosion-resistant billet stock 6061-T6 aluminum
- Contact factory about Natural Metals such as C360 brass, C932 bronze, C110 copper, and 303 / 304 stainless steel
- Fixtures constructed from 6061-T6 aluminum are double protected by an ROHS* compliant chemical film undercoating and polyester powdercoat paint finish, surpassing the rigorous demands of the outdoor environment
- A variety of standard colors are available. Custom colors available upon request: select "RALXX" option"; additional charges and lead time apply Brass, Bronze*, Copper or Stainless Steel
- Fixtures constructed from brass, bronze*, copper or stainless steel are left unpainted to reveal the natural beauty of the material
- Brass, bronze* and copper will patina naturally over time
- Hood is removable for easy relamping and accepts up to three internal accessories at once (lenses, louvers, filters) to achieve multiple lighting effects
- Model 203, 203-CRS & 203-FM: Weep holes prevent water and mineral stains from collecting on the lens
- Model 203-FL: The flush lens design minimizes debris collection and prevents water and mineral stains from collecting on the lens
Gasket
Lens- Housing and hood are sealed with a high temperature silicone o-ring gasket to prevent water intrusion
- Tempered glass lens, factory sealed with high temperature adhesive to prevent water intrusion and breakage due to thermal shock
- Model 203 and 203-FL include fully adjustable side-mounted swivel stem, providing 340 degrees tilt and 360 degrees rotation for easy aiming
- Center rear swivel (203-CRS) or stationary rear fixed mount (203-FM) models are also available
- All models include 1/2” NPS threaded male fittingStainless steel aim-locking mechanisms are standard on adjustable models
• Lumière’s exclusive Siphon Protection System
(S.P.S.) prevents water from siphoning into the
fixture through its own lead wires
Hardware
• Stainless steel hardware is standard to provide
maximum corrosion-resistance
Socket
• Ceramic socket with 250° C Teflon® coated lead
wires and GU5.3 bi-pin base.
Electrical
• Remote 12V transformer required (not included)
• Initial power draw on LED equipped fixtures is 12
watts when sizing transformer use 12 watts per
LED fixture
• Nominal power draw after start up is 8 watts
• LEDs are more voltage sensitive than standard
halogen MR16 lamps
• The LED module is designed to operate within the
range 12V +/- 1.2V. Any less or more voltage can
cause premature failures
Lamp
• Halogen lamp not included
• SORAA LED lamps are included when "8LED" or
"5LED" options are selected
• LED options are available in 2700K, 3000K, and
4000K at 95CRI; in addition to Amber (585-595nm)
• Select from three beam angles: 10° Spot, 25°
Narrow, and 36° Wide
• Both color temperature and distribution must be
specified when ordering
Compliance
• Tested to IESNA LM-79 and LM-80
• Domestic preference option available to meet BAA
requirements
• BABA domestic preference option meets BABA
requirements. BABA products meet minimum
government compliance requirements for Buy
America Build America standard, part of the
Infrastructure and Investment Jobs Act (IIJA).
Individual government agencies may have more
stringent compliance standards
• See DOMESTIC PREFERENCES website or consult
the CLS Domestic Preferences team for more
information
Shipping Data
• Approximate Net Weight: 1.08 lbs. (0.49 kgs.)
• Effective Projected Area: 9.8 in2
Warranty
• Three year warranty standard.
