Home > Lithonia Lighting > Luminis CT153 L1L180 40K 120 LD3 WM WHT 160W Clermont LED Wall Light, 16526 Lumens, 4000K, 120V, Type III Distribution, Wall Mount, Snow White
Luminis CT153 L1L180 40K 120 LD3 WM WHT 160W Clermont LED Wall Light, 16526 Lumens, 4000K, 120V, Type III Distribution, Wall Mount, Snow White
Luminis CT153 L1L180 40K 120 LD3 WM WHT 160W Clermont LED Wall Light, 16526 Lumens, 4000K, 120V, Type III Distribution, Wall Mount, Snow White
Regular price
Price:
$1,747.85
Regular price
Price:
Sale price
$1,747.85
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
MATERIALS
MATERIALS
Clermont is made of aluminum diecast offering exceptional precision and durability. The main housing is sealed with durable gasket. Features a high efficiency LED light engine, mounted on a recessed heatsink whose pattern is optimized for heat dissipation. The driver is preinstalled inside the main housing, sealed with gasket, and secured with four captive screws which makes it easy for maintenance.
ELECTRICAL DRIVER
Standard driver is 0-10V dimming-ready (dims to 10%) with: 120-277 multi-volt compatibility (50-60Hz), operating temperature range of -40°C to +55°C -40°F to +131°F, output over voltage protection, output over current protection and output short circuit protection with autorecovery.
Optional 347/480V available.
LED LIGHT ENGINE
Offered in 2700K, 3000K, 3500K & 4000K / 80CRI. 70% LED lumen maintenance at 60,000 hours (L70/B50) based on IESNA LM-80-08 LED extrapolated life, calculated per IESNA TM-21-21.
FINISH
Five-stage preparation process includes preheating of cast aluminum parts for air extraction. Polyester powder coating is applied through an electrostatic process, and oven cured for long term finish.
CERTIFICATION
UL Certified to Canadian and U.S. safety standards. Certified for use in wet locations. Rated IP66/IK10. Photometric testing performed by an independent laboratory in accordance with IES LM-79-08 standards at 25°C. Actual performance may differ as a result of end-user environment and application.
WARRANTY
5-year limited warranty. This is the only warranty provided and no other statements in this specification sheet create any warranty of any kind. All other express and implied warranties are disclaimed.
MOUNTING
Mounts aligned over a standard 4” (102mm) octagonal electrical box with a set of four additional anchoring hardware by others. For drilling pattern, refer to installation sheet.
ELECTRICAL DRIVER
Standard driver is 0-10V dimming-ready (dims to 10%) with: 120-277 multi-volt compatibility (50-60Hz), operating temperature range of -40°C to +55°C -40°F to +131°F, output over voltage protection, output over current protection and output short circuit protection with autorecovery.
Optional 347/480V available.
LED LIGHT ENGINE
Offered in 2700K, 3000K, 3500K & 4000K / 80CRI. 70% LED lumen maintenance at 60,000 hours (L70/B50) based on IESNA LM-80-08 LED extrapolated life, calculated per IESNA TM-21-21.
FINISH
Five-stage preparation process includes preheating of cast aluminum parts for air extraction. Polyester powder coating is applied through an electrostatic process, and oven cured for long term finish.
CERTIFICATION
UL Certified to Canadian and U.S. safety standards. Certified for use in wet locations. Rated IP66/IK10. Photometric testing performed by an independent laboratory in accordance with IES LM-79-08 standards at 25°C. Actual performance may differ as a result of end-user environment and application.
WARRANTY
5-year limited warranty. This is the only warranty provided and no other statements in this specification sheet create any warranty of any kind. All other express and implied warranties are disclaimed.
MOUNTING
Mounts aligned over a standard 4” (102mm) octagonal electrical box with a set of four additional anchoring hardware by others. For drilling pattern, refer to installation sheet.
