Lutron LOS-S2IR-HD-WH Passive Infrared Wall Switches, 1000 sq. ft. in White

Description

The LOS-SIR Series of infrared sensors offer a direct and quick replacement of wall switches for stand-alone line voltage switching of small spaces. The advanced microprocessor in combination with infrared technology detects occupancy and reduces energy consumption. They install quickly and easily and provide excellent energy savings as well as reliable motion detection.

Features & Benefits

• Dual 120/277 V operation
• Integral adjustable light level sensor (except LOS-SIR-M)
• Compatible with electronic ballasts and PL lamps
• No minimum load requirement
• High immunity to RFI and EMI
• 180° field of view
• Adjustable time delay
• HD models have heavy-duty lens to prevent damage
• S2IR-HD model has dual-level switching, allowing for two primary input circuits, each with independent switching

General Operation

The LOS-SIR Series of sensors monitor an established area through a PIR lens and are alerted by a moving heat source, such as a human body, which causes the sensor to automatically switch "ON" available lighting. With a fully adjustable time delay, sensitivity, and light level control, convenience and performance are optimized. The sensor's internal circuitry allows it to operate with any lighting load, including electronic ballasts, PL lamps, and exhaust fans.

Model #	LOS-S2IR-HD-WH
Type	Occupant Sensors
Color	White
Coverage	1,000 sq.ft.
Special Features	Dual-circuit; Heavy-duty lens
Adjustability	30 seconds to 30 minutes time delay 20% to 100% sensitivity Auto/Off push switch for override to “OFF”
Maximum Load Requirements	120 V: 1000 W ballast, 800 W incandescent 277 V: 1800 W ballast
Load Requirements	Low load: 0.208-2.0 A, 25-240 W @ 120 V, 60-550 W @ 277 V High load: 1.33-5.0 A, 160-600 W @ 120 V, 370-1200 W @ 277 V
Sensing	Integral light level sensor (except LOS-SIR-M) LOS-SIR and HD models 5 to 200 foot-candles Optical lens rejects “white light” and prevents false triggering Multi-segment IR lens (HD models have tamper-resistant heavy-duty lens)
Power	Operating voltage: 120/277 V, 50/60 Hz Compatible with all electronic ballasts and PL lamps No minimum load requirement S2IR-HD controls 2 circuits independently UL and CUL listed
Operating Environment	Temperature: 0°F to 100°F (-18°C to 38°C) Relative humidity: less than 95%, non-condensing For indoor use only
