Home > Lutron > Lutron-LTEA4U1UKS-ZC070 Hi-Lume 1% 2-Wire LED Driver, UL Listed / cULus Listed, Compact Case, Studded Case Style, 0.51-1A, 30-60V, Constant-Current Driver with PWM Dimming, Constant Level

  • Lutron-LTEA4U1UKS-ZC070 Hi-Lume 1% 2-Wire LED Driver, UL Listed / cULus Listed, Compact Case, Studded Case Style, 0.51-1A, 30-60V, Constant-Current Driver with PWM Dimming, Constant Level
1 1

Lutron-LTEA4U1UKS-ZC070 Hi-Lume 1% 2-Wire LED Driver, UL Listed / cULus Listed, Compact Case, Studded Case Style, 0.51-1A, 30-60V, Constant-Current Driver with PWM Dimming, Constant Level

Lutron-LTEA4U1UKS-ZC070 Hi-Lume 1% 2-Wire LED Driver, UL Listed / cULus Listed, Compact Case, Studded Case Style, 0.51-1A, 30-60V, Constant-Current Driver with PWM Dimming, Constant Level

Price: $89.80
Price: $89.80

MODEL: Lutron-LTEA4U1UKS-ZC070

Usually Ships in 3-5 business days. Urgent Project? contact us >>
Add To Wishlist
Request a Quote
Ordering a large quantity? Request a quote
View full details

description

The Hi-lume 1% 2-Wire LED Driver is a high-performance LED driver that provides smooth, continuous 1% dimming for virtually any LED fixture, whether it requires constant-current or constant-voltage. It is the most versatile LED driver offered today due to its compatibility with a wide variety of LED arrays, multiple form factors, and numerous control options.

Product Features
  • Continuous, flicker-free dimming from 100% to 1%.
  • Guaranteed compatibility with selected Maestro
  • Wireless, RadioRA 2, HomeWorks QS, GRAFIK Eye QS, GRAFIK Systems, Quantum, and C•L dimmers.
  • Please see Compatible Controls chart or contact Lutron for details regarding compatible controls.
  • QwikFig compatible. For more information please refer to Lutron P/N 041473 (K and M case only).
  • 100% performance tested at factory.
  • A rated lifetime of 50,000 hours @ tc =149 °F (65 °C).
  • UL recognized and listed options for United States and Canada.
  • NOM certified option for Mexico.
  • Type TL Rated.
  • FCC Part 15 compliant for commercial and residential
  • (UL Listed only) applications at 120 V~.
  • Pulse width modulation (PWM) or constant-current reduction (CCR) dimming methods available. See Application Note #360 for details.
  • RoHS Compliant
