Metalux 14CZ-LD5-39-SQP-UNV-L835-CD1-U 1'x4' Cruze LED, 3900 Lumens, Smooth Lens with Square Pattern Insert, 120-277V, 80 CRI, 3500K, 0-10V Driver, 1 Driver

Metalux 14CZ-LD5-39-SQP-UNV-L835-CD1-U 1'x4' Cruze LED, 3900 Lumens, Smooth Lens with Square Pattern Insert, 120-277V, 80 CRI, 3500K, 0-10V Driver, 1 Driver

Price: $301.13
Price: $301.13

MODEL: Metalux-14CZ-1644
Add To Wishlist
Request a Quote
Ordering a Large Quantity? Request a quote
View full details

description

PRODUCT FAMILY SPECIFICATIONS
Construction
  • Die formed of code gauge prime cold rolled steel with full length die-formed stiffeners
  • Unibody endplates attached with interlocking tabs and screws
  • Hemmed side flanges
  • Four auxiliary fixture end suspension points provided
  • Optional earthquake clips available
Integrated Controls
  • 0-10V dimming to 1% standard
  • Integrated WaveLinx options provide wireless individual fixture control and enable code compliance, increased energy savings, grouping of fixtures, and connection to WaveLinx control systems
  • DALI 2.0, Lutron, and step-dimming available
LED and Light Engine
  • Long-life LED systems coupled with electrical driver
  • Color accuracy ≤3-Step MacAdam ellipse (SDCM)
  • Available in 3000K, 3500K, 4000K, or 5000K with a minimum CRI of 80
  • L70 is more than 60,000 hours based on TM21 testing standards
  • Available in 120-277V and 347V
Emergency Battery Options
  • 120V-277V integral emergency battery pack comes in 7-watts, 10-watt, or 14-watts
  • Self-diagnostic emergency battery available in 10 or 14-watts (NFPA 101® Life Safety Code®)
  • Constant power to the LED system for controlled, predictable discharge
  • Integrated test switch/indicator light visible from floor
  • Min. 90-minute backup period for code compliance
  • Integral emergency transfer relay available for generator equipped power systems WNPS - WaveLinx Normal Power Sensing
  • Normal Power Sensing (NPS) wireless beacon enabled luminaire that signals normal power is present
  • Must be ordered with WaveLinx LITE or PRO sensor as part of a WaveLinx control system
  • For UL924 compliance, WNPS enabled luminaires with standard product and compatible emergency control devices (ESP-P/ESP-L) must be installed in same application space
WEM - WaveLinx UL924 Emergency Sensor
  • Emergency control devices (ESP-P/ESP-L) not required when WEM and WNPS luminaires are installed in the same application space
  • For UL924 compliance, order WEM and WNPS luminaires in the same application space
  • WEM must be ordered with WLS or WPS sensor as part of a WaveLinx control system
Hinging/Latching
  • Positive cam action steel latches with baked white enamel finish
  • Safety-lock T-hinges allow hinging and latching either side
  • Door assembly hinges down for easy access from below
Frame/Shielding
  • Die formed, heavy gauge flat steel door
  • Mitered corners and painted after fabrication
  • Baked matte white enamel finish
  • Positive light seals
  • Acrylic frosted lens
  • Replacement lenses available, contact factory
  • Lens is acrylic with features on the face and sides to optimize the direct and indirect lighting contributions for improved glare and efficacy
Compliance
  • IC rated for insulation contact
  • cULus listed for damp locations
  • RoHS compliant
  • Tested to IESNA LM-79 and LM-80
  • Stated life tested to TM21 standards
  • Can be used for State of California Title 24 high efficacy luminaire
BABA Domestic Preference Compliance
  • FHWA and FTA agencies are utilizing their BAA rules for BABA compliance. Cooper’s products with a BAA designation are manufactured in the US and utilize a BAA COTS exemption rule for compliance. To verify a configured product with specific accessories and options meet BABA Domestic Preference Requirements; submit this catalog number to Cooper Lighting Quotation team for validation by our Engineering and Manufacturing teams. Please refer to the DOMESTIC PREFERENCES website or consult the CLS Domestic Preferences team for more information. Components shipped separately may be separately analyzed under domestic preference requirements.
Warranty
  • Five-year limited warranty standard
