Metalux 22CZ-LD5-24-S-UNV-L835-CD1-U 2'x2' Cruze LED, Smooth Lens, 2400 Lumens, 120-277V, 3500K, 0-10V 1%-100% Dimming
Metalux 22CZ-LD5-24-S-UNV-L835-CD1-U 2'x2' Cruze LED, Smooth Lens, 2400 Lumens, 120-277V, 3500K, 0-10V 1%-100% Dimming
Regular price
Price:
$203.45
Regular price
Price:
Sale price
$203.45
Unit price
per
MODEL: Metalux-22CZ-549
Usually Ships in 4-6 business days. Urgent Project? Contact Us
Couldn't load pickup availability
Ordering a large quantity?Request a quote
description
PRODUCT DESCRIPTION
The CruzeSB LED series combines contemporary styling and optimal Illumination design with features to enable service from below (SB). This high performance LED troffer is constructed with Cooper Lighting Solutions' latest solid-state technology platform and delivers unprecedented energy savings and aesthetics at an incredible value.
The CruzeSB LED series combines contemporary styling and optimal Illumination design with features to enable service from below (SB). This high performance LED troffer is constructed with Cooper Lighting Solutions' latest solid-state technology platform and delivers unprecedented energy savings and aesthetics at an incredible value.
Cruze SB offers a perfect balance of form and function making it an ideal choice for commercial office spaces, schools, hospitals, and retail merchandising areas.
PRODUCT SPECIFICATIONS
Construction
ControlsPRODUCT SPECIFICATIONS
Construction
- Die formed of code gauge prime cold rolled steel with full length die-formed stiffeners
- Unibody endplates attached with interlocking tabs and screws
- Hemmed side flanges
- Four auxiliary fixture end suspension points provided
- Optional earthquake clips available
- 0-10V dimming to 1% standard
- WaveLinx wireless fixture for sensor-less wireless control
- WaveLinx wireless sensor compatible for standalone, controlled, connected, and IoT capability
- SVPD sensor compatible for standalone functionality
- Low-voltage sensor and driver compatible for DLVP applications
- DALI 2.0, Lutron, and step dimming available
- Long-life LED systems coupled with electrical driver
- Color accuracy ≤3-Step MacAdam ellipse (SDCM)
- Available in 3000K, 3500K, 4000K, or 5000K with a minimum CRI of 80
- L70 is more than 60,000 hours based on TM21 testing standards
- Available in 120-277V and 347V
- 120-277V battery available in 7W or 14W
- 90-minute backup period for code compliance
- Test switch with laser pointer and testing from floor feature for ease of use
- EZ Key feature prevents accidental discharge during constructio
- Generator transfer options available
- Multistage, iron phosphate pretreatment
- Housing finished with 90% white enamel
- Positive cam action steel latches with baked white enamel finish
- Safety-lock T-hinges allow hinging and latching either side
- Door assembly hinges down for easy access from below
- Die formed, heavy gauge flat steel door
- Mitered corners and painted after fabrication
- Baked matte white enamel finish
- Positive light seals
- Acrylic frosted lens
- IC rated for insulation contact
- cULus listed for damp locations
- RoHS compliant
- Test to IESNA LM-79 and LM-80
- Stated life tested to TM21 standards
- Can be used for State of California Title 24 high efficacy luminaire
Warranty
Five year warranty standard.
Five year warranty standard.
