Metalux 24ARS-L3C3-HO-UNV 2'x4' Achieva LED Troffer, Single Carton, 80 CRI
Metalux 24ARS-L3C3-HO-UNV 2'x4' Achieva LED Troffer, Single Carton, 80 CRI
Regular price
Price:
$109.15
Regular price
Price:
Sale price
$109.15
Unit price
per
MODEL: Metalux-24ARS-1368
Usually Ships in 3-5 business days. Urgent Project? Contact Us
Couldn't load pickup availability
Ordering a large quantity?Request a quote
description
PRODUCT SPECIFICATIONS
Construction
Construction
- Die formed of code gauge prime cold rolled steel in one-piece housing desig
-
Four auxiliary fixture end suspension point
- Integral formed one-piece housing improves aesthetic design removing end plate light gaps
- Integrated T-Grid clip design for screw installation to the grid where required by code and in "earthquake" zones
Integrated Controls
- Standard 0-10V dimming driver down to 5%
- Integrated WaveLinx options provide wireless individual fixture control and enable code compliance, increased energy savings, grouping of fixtures, and connection to WaveLinx control system
LED and Light Engine
- Selectable Color temperature choices 3500K, 4000K, and 5000K
- Selectable lumen output up to 8000 lumens, with choices of low, medium, high
- TM21 life at 60,000 hours up to L94 and calculated L70 exceeds 290,000 hrs.
- Driver 120-277V Standard
Emergency Options
- Optional emergency battery available in 7W and 14W
- 90-minute backup period for code compliance
- Factory installed integral test switch visible from room side
Finish
- Powder Coat matte white
- 90% reflective, matte white enamel finish
- Full fixture housing painted after fabrication
Shielding
- Rounded ribbed frosted lens standard
- Square ribbed frosted option coming Q1 (Consult Factory)
Compliance
- IC rated for insulation contact
- cULus listed for damp locations
- RoHS compliant
- Tested to IESNA LM-79 and LM-80
- Stated life tested to TM21 standards
- Can be used for State of California Title 24 high efficacy luminaire
- Can be use for Non-residential T24
- DesignLights Consortium Qualified and classified for DLC Standard and DLC Premium (refer to www.designlights.org)
Limited Warranty
- Five-year warranty standard
Download PDF Specification Share your knowledge of this product. Be the first to write a review »
