Metalux 24FPX-31-L850 2' x 4' LED Flat Panel, 3100 Lumens, 120-277V, 5000K Color Temperature, Standard Efficacy, CD Driver
Metalux 24FPX-31-L850 2' x 4' LED Flat Panel, 3100 Lumens, 120-277V, 5000K Color Temperature, Standard Efficacy, CD Driver
Regular price
Price:
$258.00
Regular price
Price:
Sale price
$258.00
Unit price
per
MODEL: Metalux-24FPX-31-L850
Usually Ships in 4-6 business days. Urgent Project? Contact Us
Couldn't load pickup availability
Ordering a large quantity?Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
Construction
Construction
- Narrow aluminum bezel is tightly held to a dieformed code gauge steel back plate with flush perimeter and internal gasket
- Seamless corners to maximize the light emitting surface with a refined finish
- Integral grid clips and separate suspension clips provided for installation flexibility when additional retention is required
- Junction box constructed of code gauge galvanized steel with an easy access hinged door
- Multiple trade size knockouts provided on the top and sides
- Stock luminaire is less than 2.5" for use in shallow plenum or low ceiling spaces
- Surface mounting kits available
- Suspension options available from factory
- CCEA (Chicago Plenum) rating options available
- Factory installed flexible cable with dimming leads options available
- Standard with 0-10V dimming driver (10% standard, 1% optional)
- WaveLinx wireless sensor compatible for standalone, controlled, connected, and IoT capability
- SVPD sensor compatible for standalone functionality
- Low-voltage sensor and driver compatible for WaveLinx Low-Voltage and DLVP applications
- DALI 2.0, Lutron, and step-dimming available
- Standard and High Efficacy models available
- LED’s available in 3000K, 3500K, 4000K, and 5000K with a minimum of 80 CRI
- Color accuracy ?3-Step MacAdam ellipse (SDCM)
- Projected lumen maintenance based on TM21 testing standards is L73 > 60,000 hours
- Five year warranty.
- Light guide with specialized features to optimize light extraction
- White frost lens with smooth pattern for uniform illumination
- Scratch and impact resistant
- Indoor luminaires are cULus listed for 25C ambient environments
- IC rated for direct insulation contact
- RoHS compliant
- Damp location listed
- IESNA LM-79 and LM-80 standards compliant
- Can be used for State of California Title 24 high efficacy luminaire
- Meets IP5X rating from the room side with no modification needed
- 120V-277V integral emergency battery pack comes in 7-watts, 10-watt, or 14-watts
- Self-diagnostic emergency battery available in 10 or 14-watts (NFPA 101 Life Safety Code)
- Constant power to the LED system for controlled, predictable discharge
- Integrated test switch/indicator light visible from floor
- Min. 90-minute backup period for code compliance
- Integral emergency transfer relay available for generator equipped power systems
Download PDF SpecificationShare your knowledge of this product. Be the first to write a review »
